Page 4

3
Position Switch Kit for Retrofill CB
DEH-41530 02/12
Figure 1. Position Switch, an Example
• Turn off all power to switchgear. Tagout
and lockout main source, up-stream or
main breaker.
• Failure to comply with these instructions
will result in death or serious injury from
severe burns caused by arc flashing that
has exceedingly high temperatures.
• Always wear personal protection equipment
according to OSHA standards and appropriate
to the severity of potential burns.
• Ensure only qualified personnel install, operate, service, and maintain all electrical equipment.
The mechanical subassembly comes with mounting hardware, lever, and bracket. Depending on the switchgear,
this simple device is mounted in different locations.
Note:
• It is strongly advised that the LVS (low voltage switchgear) be switched off/de-energized before you assemble
and mount the position switch actuator.
• The compartment position switch assembly is not part of the retrofill kit. If the customer desires to install or
replace a position switch assembly in the compartment, the customer can order it separately. Refer to
Table 1
.
