Data Sheet
CAR2512FP series rectifier
Input: 90Vac to 264Vac; Output: 12 Vdc @ 208A; 3.3Vdc or 5 Vdc @ 1A
March 28, 2013
©2013 General Electric Company. All rights reserved.
Page 4
Feature Specifications (continued)
Parameter
Symbol
Min
Typ
Max
Unit
Output Voltage programming (Vprog)
Equation: Vout = 10.8 + (Vprog * 0.96)
Vprog range
V
prog
0
2.5 V
DC
Programmed output voltage range
Vo
10.8
13.2 V
DC
Voltage adjustment resolution (8-bit A/D)
Vo
10
mV
DC
Output configured to 13.2Vdc
V
prog
2.5
3.0 V
DC
Output configured to the 12Vdc set-point
V
prog
3.0
V
DC
Enable [short pin controlling presence of the 12V
DC
output]
12V output OFF
V
I
0.7V
DD
12 V
DC
12V output ON
V
I
0
0.8 V
DC
Write protect (Wp)
Write protect enabled
V
I
0.7V
DD
12 V
DC
Write protect disabled
V
I
0
0.8 V
DC
INPUT(AC)-OK (Needs to be pulled HI via an external resistor)
Logic High (Input within normal range; V
IN
≥ 80V
AC
) I
OH
20 µA
V
OH
0.7V
DD
12 V
DC
Logic Low (Input out of range; V
IN
≤ 75V
AC
) I
OL
20 mA
V
OL
0
0.4 V
DC
DC-OK ( Internally connected to 3.3V via a 10kΩ resistor)
Logic High (Output voltage is present; V
OUT
≥ 10.7Vdc)
I
OH
20 µA
V
OH
0.7V
DD
12 V
DC
Logic Low (Output voltage is not present; V
OUT
≤ 10.2V
DC
) I
OL
20 mA
V
OL
0
0.4 V
DC
Over Temperature Warning (Needs to be pulled HI via an external
i t )
Logic High (temperature within normal range)
I
OH
20 µA
V
OH
0.7V
DD
12 V
DC
Logic Low (temperature is too high)
I
OL
20 mA
V
OL
0
0.4 V
DC
Delayed shutdown after Logic Low transition
Tdelay
10
sec
Fault (Needs to be pulled HI via an external resistor)
Logic High (No fault is present)
I
OH
20 µA
V
OH
0.7V
DD
12 V
DC
Logic Low (Fault is present)
I
OL
20 mA
V
OL
0
0.4 V
DC
PS Present (Needs to be pulled HI via an external resistor)
Logic High (Power supply is not plugged in)
Logic Low (Power supply is present)
V
IL
0
0.1 V
DC
