GE
Data Sheet
CAR2512FP series rectifier
Input: 90Vac to 264Vac; Output: 12 Vdc @ 208A; 3.3Vdc or 5 Vdc @ 1A
March 28, 2013
©2013 General Electric Company. All rights reserved.
Page 2
Absolute Maximum Ratings
Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. These are absolute stress ratings only, functional
operation of the device is not implied at these or any other conditions in excess of those given in the operations sections of the data sheet.
Exposure to absolute maximum ratings for extended periods can adversely affect the device reliability.
Parameter
Symbol
Min
Max
Unit
Input Voltage: Continuous
VIN
0
264
V
ac
Operating Ambient Temperature
TA
-10
70
1
°C
Storage Temperature
Tstg
-40
85
°C
I/O Isolation voltage to Frame (100% factory Hi-Pot tested)
1500
V
ac
Electrical Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, load, and temperature conditions.
INPUT
Parameter
Symbol
Min
Typ
Max
Unit
Operational Range
V
IN
90
110/230
264 V
ac
Frequency Range
F
IN
47 50/60 63 Hz
Main Output Turn_OFF
V
IN
80
V
ac
Maximum Input Current, (V
IN
= 180Vac, V
O
= V
O, set
, I
O
=I
O, max
) I
IN
16
A
ac
Cold Start Inrush Current
I
IN
50
A
peak
(Excluding x-caps, 25C, <10ms, per ETSI 300-132)
Efficiency, (T
amb
=25C, V
in
= 230Vac, V
out
= 48Vdc, I
O
=I
O, max
)
92
%
Power Factor, (Vin=230Vac, I
O
=I
O, max
) PF
0.99
Holdup time, (Vin= 230Vac, Vout= 48Vdc, Tamb 25C,
I
O
=I
O, max
)
T 16.8 ms
Early warning prior to loss of DC output below regulation
2
ms
Ride through
T
8.3
ms
Leakage Current, (Vin= 250Vac, Fin = 60Hz)
I
IN
3
mArms
Isolation Input/Output
3000 V
ac
Input/Frame
1500
V
ac
Output/Frame
100
V
dc
48V
dc
MAIN OUTPUT
Parameter
Symbol
Min
Typ
Max
Unit
Output Power High Line Operation (180 – 264 Vac)
W
0 - 2500
W
Low Line Operation: 99Vac [Z03A/Z01A]
90 – 98 Vac [Z03A/Z01A]
0
0
-
1300/1000
1200/1000
W
Set point
V
out
47.95 48.00 48.05 V
dc
Overall regulation (load, temperature, aging)
-3
+3
%
Ripple and noise
2
540
mV
p-p
Turn-ON overshoot
+3
%
Turn-ON delay
T
2
sec
Remote ON/OFF delay time
40
ms
Turn-ON rise time (10 – 90% of V
out
)
50
ms
1
Derated above 50C at 2.5%/C
2
Measured across a 10µf electrolytic and a 0.1µf ceramic capacitors in parallel. 20MHz bandwidth
