Sena Technologies, Inc 53
B.3.3. AT
Response  OK
Purpose Check the connection status with host equipment
Description Check if the connection to host equipment is operating normally. The serial parameters
of Parani-BCD110V3 must be same as those of host equipment. If not, the Parani-
BCD110V3 will not respond or ‘ERROR’ message will appear or an abnormal sequence
of strings will appear.
B.3.4. ATEx
Response  OK
Purpose Set serial echo
Parameters x = 0/1 (Default=0)
Description Serial echo can be set or changed. If it is set to 1, serial input is echoed.
B.3.5. AT+UARTCONFIG,Baudrate,Parity,Stopbit,Hwfc
Response  OK
Purpose Set Serial parameters
Parameters Baudrate=1200/2400/4800/9600/14400/19200/38400/57600/115200/230400/460800/
921600 (Default=9600)
Parity=N/E/O (Default=N)
Stopbit=1/2 (Default=1)
Hwfc(Hardware Flow Control)=0/1 (Default=1)
Description The Serial parameters can be set or changed. The factory default is 9600, N, 1, 1.
To take effect, the ATZ command must be used or Power cycle of the unit.
Example AT+UARTCONFIG,115200,N,1,1
B.3.6. AT+BTINFO?
Response  112233445566,DeviceName,Mode,Status,Auth,Encryp,FlowControl
 OK
Purpose Display Bluetooth settings
Description The current Bluetooth settings are displayed including BD address, Device name,
Operation mode, Operation status, Authentication, Data Encryption, and Hardware Flow
Control. The initial value of Device name is ‘BCD110_v3.0.0-445566’. BCD110 stands
for Parani-BCD110, v3.0.0 for the version of firmware, and 445566 for the last 6 digits
of BD address.
Mode=MODE0/MODE1/MODE2/MODE3
Status=STANDBY/PENDING/CONNECT(NN)
Auth=0/1 (Authentication is not activated when 0)
