Sena Technologies, Inc 47
Table A-4 Pairing Process with multiple Bluetooth devices by Pairing Signal
Master Status Slave Status
1. Factory Reset Mode0
2. Slave 1,2,3,4,5,6,7 Factory reset Mode0
3. Slave 1,2,3,4,5,6,7Drop pairing
signal Mode3
4. Drop pairing signal Mode3
5. Drop pairing signal Mode1
6. Slave1 connected Mode1 6. Slave 1 connected Mode2
7. Drop pairing signal Mode1
8. Changed Multi-Drop Mode Mode1 6. Slave 1 disconnected Mode2
9. Slave 1 connected Mode1 9. Slave 1 connected Mode2
10. Changed Multi-Drop Mode Mode1
11. Slave 2 connected Mode1 11. Slave 2 connected Mode2
12. Changed Multi-Drop Mode Mode1
13. Slave 3 connected Mode1 13. Slave 3 connected Mode2
14. Changed Multi-Drop Mode Mode1
15. Slave 4 connected Mode1 15. Slave 4 connected Mode2
16. Changed Multi-Drop Mode Mode1
17. Slave 5 connected Mode1 17. Slave 5 connected Mode2
18. Changed Multi-Drop Mode Mode1
19. Slave 6 connected Mode1 19. Slave 6 connected Mode2
20. Changed Multi-Drop Mode Mode1
21. Slave 7 connected Mode1 20. Slave 7 connected Mode2
A.1.5. Reset (RESETB) Signal
Parani-BCD110V3 can be reset from one of following sources:
 RESETB pin
 Power on reset
The RESETB pin is an active low signal and is internally filtered using the internal low frequency
clock oscillator. A reset will be performed between 1.5 and 4.0ms following RESETB being active.
So it is recommended that RESETB be applied for a period greater than 5ms.
A.1.6. PVCC Input
If PVCC input is not wired or input power is lower than 3.3V, working distance may be less than
that of the product specification which is 200m(0.12 mile) by defalut antenna and 1000m(0.62
mile) at maximum.
