ProBee-ZE20S User Guide Rev.1.10

++0001950000000212|11000000000**0000|****,****,21D0,0B87,****,****

++0001950000000212|11000000000**0000|****,****,21CB,0324,****,****

# Data changes after covering sensors with fingers

++0001950000000212|11000000000**0000|****,****,229B,0084,****,****

++0001950000000212|11000000000**0000|****,****,22A7,009E,****,****

++0001950000000212|11100000000**0000|****,****,22A9,002D,****,****



Data displayed at coordinator every second



Data format : ++<IEEE address>||



Refer to 6.6.7 Data Conversion about how to convert to analog data to temperature and

illumination

6.6.6

Periodic Sampling – Sink Node

6.6.6.1 Coordinator Configuration

The AT commands for Coordinator Configuration:

ATS11=1

# Set coordinator to receive incoming data

# Response

ATS61=10

# Set coordinator to sink node which multicasts its

# address to the devices in AT+DESTGROUPID every 10 sec.

# Response

ATZ

# Apply configuration

# Response

6.6.6.2 Router Configuration

The AT commands for Router Configuration:

AT+DESTLA=0000000000000000

# Reset destination to send analog data (Destination address does not

# affect on sending analog data to sink node but reset destination to

# confirm that analog data are sent to sink node)

# Response

ATS42=1

# Period to send analog data to sink node (unit : second)

# Response

ATS43=1

# Set destination to sink node

# ATS43=0 sets destination to AT+DESTLA

ATZ

# Apply configuration

# Response
