the digital I/O line values, the AT+DIO command can be used as below. Return value is a combination of
0 (Low) and 1 (High) if the pins are configured as digital I/O lines. If the pins are configured as analog
inputs, the corresponding return values are shown as *.
AT+DIO? or AT+DIO?
, where is the specific IO number between ranges 0 ~ 16 to read
AT+DIO command can also be used to set the digital output lines.
AT+DIO= or AT+DIO=
, where is the specific IO number between ranges 0 ~ 16 to read, and the is a
combination of 0 or 1, 0 = Low, 1 = High
The analog input values can be read using the AT+AI command. Return value is a combination of 16-bit
hexadecimal integer between 0~2EE0(0~1200.0mV) which unit value corresponds to 0.1mv. To convert
the hexadecimal value to the actual voltage, please use the formula below. If the pins are configured as
digital I/Os, the corresponding return values are shown as *.
AT+AI? or AT+AI?
, where is the specific IO number between ranges 0 ~ 5 to read
If the Value is between 0 ~ 7FFF, Voltage (mV) = Value * 0.1
If the Value is between 8000 ~ FFFF, Voltage (mV) = (Value – 65536) * 0.1
Example)
AT+DIO?
10001000111**0000  DIO 0, 4, 8, 9, 10 are ON. GPIO11, 12 are configured
as analog inputs
OK
AT+DIO0=0
OK
AT+DIO?
00001000111**0000  DIO 4, 8, 9, 10 are ON. GPIO11, 12 are configured as
analog inputs
OK
AT+AI?
****,****,192A,13E8,****,****  AI 2, 3 are used. (GPIO11, 12) The others
are configured as DIO.
OK
