SENA UPSLink100 - Manual (Page 32)

32
Figure 0-5 Access control configuration
A user may specify more than one host as allowed to configure the UPSLink. The user must then
enter the IP address or subnet mask to include all the necessary hosts.
The user may also allow only a specific host to have configuration access to the UPSLink by entering
the specific IP Address with the static subnet mask: 255.255.255.255. The user must then be on the
specified host to gain access to the UPSLink.
The user may want to allow any host to gain access to the UPSLink. The user may then enter “0.0.0.0”
for host IP and “0.0.0.0” for subnet. Please refer to Table 0-3 for more details. The device’s default
setting of allowed remote hosts for configuration is “Any”.
Input format
Allowed Hosts
Base Host IP address Subnet mask
Any host 0.0.0.0 0.0.0.0
192.168.1.120 192.168.1.120 255.255.255.255
192.168.1.1 ~ 192.168.1.254 192.168.1.0 255.255.255.0
192.168.0.1 ~ 192.168.255.254 192.168.0.0 255.255.0.0
192.168.1.1 ~ 192.168.1.126 192.168.1.0 255.255.255.128
192.168.1.129 ~ 192.168.1.254 192.168.1.128 255.255.255.128
Table 0-3 Input examples of allowed remote hosts
4.6 SYSLOG server configuration
The UPSLink supports a remote message logging service, SYSLOG service for the system and UPS
alarm data logging. To use the remote SYSLOG service, the user must specify the SYSLOG server’s
IP address and the facility to be used. Figure 0-6 shows the SYSLOG server configuration page of the
supplied Web interface. The UPSLink provides a maximum of two SYSLOG servers. If the secondary
SYSLOG server is configured, the UPSLink will send the same SYSLOG messages to both servers.
