Per Channel Settings
Channel Attenuators
Each channel is supplied with a logrithmic 21-position detented input attenuator. Use a flat-blade screwdriver to set input level. Attenuation is from -95 dB
(full counter-clockwise) to 0 dB (full clockwise). For gain structure purposes, it is important to note that attenuators are at the end of the DSP signal chain.
Position 0 1 2 3 4 5 6 7 8 9 10
Typical
Attenuation
0 -0.1 -1 -2 -3 -4 -5 -6 -7 -8 -9
Position 11 12 13 14 15 16 17 18 19 20
Typical
Attenuation
-10 -13 -16 -20 -30 -40 -50 -60 Mute Mute
