Set-up and System Configuration
Figure 7 (above) shows the DriveCore Install 2 channel configuration page. The 4 and 8 channel amplifier configuration pages have the same feature set. The
DriveCore Install Network amplifier includes Digital Signal Processing (DSP), multiple input/output routing options and a comprehensive diagnotics feature set.
All of these features can be adjusted in from the configuration page.
Amplifier Mode Settings
Hi-Z/Low-Z
The DriveCore Install Network amplifiers are capable of High Z and Low Z outputs. Each individual channel is capable of Hi-Z or Low-Z operation. To select Hi-Z or Low-Z
operation, double click on the mode button, the Amplifier Mode Setting Window will open (see Figure 8). Note: Choosing 70Vrms or 100Vrms is an amplifier global setting,
and affects all output channels selected for High-Z operation.
Figure 8
Global
Channel
Specific
The DriveCore Install amplifiers are very capable and flexible amplifiers. In the Amplifier Mode Setting window, the following items can be adjusted.
• Hi-Z/Low-Z on an individual channel basis.
• 70Vrms or 100Vrms operation
• Any analog input can be sent to any amplifier output
• Mono Bridge Output - Output pairs can be bridged for mono operation
