SM6000

Page 1 - 4

SPECIFICATIONS

Rev. Sept. 2012

EMC

Power Sup ply Stan dard

Ge neric Emis sion
Ge neric Im mu nity

EN 61204-3,

Emis sion: res i den tial, light in dus trial en vi ron ment (CISPR22-Class

B

)

Im mu nity: in dus trial en vi ron ment

EN 61000-6-3, res i den tial, light in dus trial en vi ron ment (EN 55022

B

)

EN 61000-6-2, in dus trial en vi ron ment

Op er at ing Tem per a ture at full load

− 20 to + 50 °C

de rate out put to 75% at 60 °C

Hu mid ity

max. 95% RH, non con dens ing, up to 40 °C

max. 75% RH, non con dens ing, up to 50 °C

Stor age tem per a ture

− 40 to + 85 °C

Ther mal pro tec tion

Out put shuts down in case of in suf fi cient cool ing

MTBF

500 000 hrs

SM

15-400 SM

30-200 SM

45-140 SM

60-100

SM

70-90

SM

120-50 SM

300-20 SM 600-10

Hold-Up time

V

out

= 100%,

I

out

= 100%

V

out

= 85%,

I

out

= 100%

V

out

= 100%,

I

out

= 50%

@ 400 V AC in put

11 ms
23 ms
33 ms

11 ms
23 ms
28 ms

11 ms
23 ms
27 ms

11 ms
24 ms
28 ms

13 ms
23 ms
30 ms

13 ms
24 ms
32 ms

12 ms
24 ms
28 ms

11 ms
23 ms
27 ms

Turn on de lay

af ter mains switch on

200 ms

In rush cur rent

20 A (elec tronic limit)

Phase loss

Out put shuts down in case of phase loss

Se ries op er a tion

max. to tal volt age
Mas ter / Slave op er a tion

600 V

yes

600 V

yes

600 V

yes

600 V

yes

600 V

yes

600 V

yes

1200 V

yes

1200V

yes

Par al lel op er a tion

Nor mal
Mas ter / Slave op er a tion

no limit

max. 3 units

Re mote sens ing

max. volt age drop per load lead

2 V

Lim its

Volt age

ad just range

Cur rent

ad just range

0 - 102%
0 - 102%

Front panel CV/CC-con trols
res o lu tion
knob op er a tion
screw driver ad just ment

Lock func tion for CV/CC-set tings
Selectable Start-up at 0V / 0A or
at last set tings

an a log po ten ti om eters

1)

10 turns (0.03%)

stan dard

op tional (P001)

no
no

1)

op tional with dig i tal encoders (P220) : spec i fi ca tions

for con trols are sim i lar to SM300-20 and SM600-10.

dig i tal encoders
10 or 64 turns

2)

stan dard

no

yes

yes

2)

vari able pitch de pend ing on

op er a tion speed

Me ters

scale

volt age

scale

cur rent

ac cu racy read out put

read limit set ting
(d = digit)

3.5 digit

0 - 15.00 V

0 - 400 A

0.5% + 2 d

2% + 2 d

3.5 digit

0 - 30.0 V

0 - 200 A

0.5% + 2 d

2% + 2 d

3.5 digit

0 - 45.0 V

0 - 140.0 A

0.5% + 2 d

2% + 2 d

3.5 digit

0 - 60.0 V

0 - 100.0 A

0.5% + 2 d

2% + 2 d

3.5 digit

0 - 70.0 V
0 - 90.0 A

0.5% + 2 d

2% + 2 d

3.5 digit

0 - 120.0 V

0 - 50.0 A

0.5% + 2 d

2% + 2 d

3.5 digit

0 - 300 V

0 - 20.0 A

0.5% + 2 d

2% + 2 d

3.5 digit

0 - 600 V

0 - 10.0 A

0.5% + 2 d

2% + 2 d

Mount ing

Stack ing of units al lowed, air flow is from left to right.

In put Ter mi nals

Screw Ter mi nals for ca ble 2.5 - 4 mm

2

, 3 phase + earth (no neu tral re quired)

Out put Ter mi nals

M12 bolts

M10 bolts

M10 bolts

M10 bolts

M10 bolts

M8 bolts

M8 bolts

M8 bolts

Pro gram ming con nec tor

15 pole D-con nec tor at rear panel (FE MALE)

Cool ing

au dio noise level

air flow

Low noise blower, fan speed adapts to tem per a ture of in ter nal heatsink.

ca. 56 dBA at full load, 25 °C am bi ent tem per a ture, 1 m dis tance
ca. 62 dBA at full load, 50 °C am bi ent tem per a ture, 1 m dis tance

From left to right

En clo sure

de gree of pro tec tion

IP20

Di men sions

be hind front panel: h x w x d
front panel: h x w

177 x 443 x 500 mm

177 x 483 mm (19", 4 U)

Weight

27 kg
