Uninterruptible Power Supplies
Models and Ratings
MODEL
OUTPUT POWER
OUTPUT CURRENT
AUTONOMY
VA
Watts
(at 230VAC)
(single battery string, full load)
WM1500-x
1500VA
1050W
6.5A
9 Minutes
MODEL
OUTPUT POWER
OUTPUT CURRENT
AUTONOMY
VA
Watts
(at 115VAC)
(single battery string, full load)
WM1500L-x
1500VA
1050W
13.0A
9 Minutes
Where x in model number can be 1, 2, 3 or 4 and refers to the number of battery sets fitted
Accessory Products
Xi S
SNMP Network Adaptor Option Card replaces USB port, allowing the UPS to be addressed directly on the LAN
Xi V
AS400 Volt Free Contact Option Card replaces USB comms port with a 15 way D-type connector
Providing Utility Fail, Battery Low, Bypass & UPS Alarm Contacts
Option Order Codes
Options
(1)
E.G. WM1500-2SX
WM1500 series, 2 battery sets fitted
With SNMP network adaptor and 10 year design life batteries
Options (Examples)
Add suffix ‘S’ to Model Number - Adds internal SNMP to UPS (in place of USB port)
Add suffix ‘V’ to Model Number - Adds AS400 VFC to UPS for Utility Fail, Bypass, Battery Low and UPS Fault (in place of USB port)
Add suffix ‘X’ to Model Number - Replaces 5 year design life batteries with 10 year
Add suffix ‘Z’ to Model Number - IP45 Ingress Protection
(1) Options should be listed in alphabetical order
WM1500-x
Run Time Charts
UPS
Model
Standard Run Time in Minutes (Autonomy vs Load)
200VA
400VA
600VA
800VA
1000VA
1500VA
(140W)
(280W)
(420W)
(560W)
(700W)
(1050W)
WM1500(L)-1
86
39
24
17
12
9
WM1500(L)-2
199
85
54
39
29
18
WM1500(L)-3
328
142
90
62
49
30
WM1500(L)-4
450
328
120
86
68
43
-1, -2, -3, -4, in model number refers to the number of battery sets fitted
Weights & Dimensions
UPS
Unit Dimensions (mm)
Unit Weight
Model
Height
Depth
Width
(total kg)
WM1500(L) [Internal Electronics Module]
410
130
545
12.0
WM1500(L)-1 [Wall cabinet with 1 battery set]
765
240
620
43.5
WM1500(L)-2 [Wall cabinet with 2 battery sets]
765
240
620
54.0
WM1500(L)-3 [Wall cabinet with 3 battery sets]
765
240
620
64.5
WM1500(L)-4 [Wall cabinet with 4 battery sets]
765
240
620
75.0
Dimensions include mounting brackets
-3 & -4 models supplied with 100mm plinth for floor mounting due to weight
