Spec i fi ca tions – Powersolve SX Series User Manual
Page 2
In dex of pos si ble volt age / cur rent com bi na tions
De rating of out put cur rent at low line volt age
In put
:
Autoranging
75 W
150 W
75 W
150 W
AC 98 - 132 V 48 - 62 Hz
1.3 Arms
2.6 Arms
Fuse
2 A T
4 A T
185 - 264 V 48 - 62 Hz
0.7 Arms
1.4 Arms
For DC op er a tion and op er a tion at 400 Hz con tact fac tory.
In rush cur rent limit
:
10 A with NTC re sis tor 30 Ohms
cold re sis tance.
In su la tion
In put / out put
:
4 kVrms (1 min.), 8 mm creepage/cl.
In put / case
:
2.5 kVrms (1 min.), 5 mm creepage/cl.
Out put / case
:
500 V DC, 1 mm creepage/clear ance
1 kV DC for 150SX75-75 and 200-200.
Safety
:
EN 60950 EN 61010
EMC
:
EN 61204-3
Power Sup ply Stan dard
EN 61000-6-3
(EN 55022B) Ge neric Emis sion
EN 61000-6-2
Ge neric Im mu nity
Ef fi ciency
:
84 % dual units, 80 % 5V units at 230 V AC in put.
81 % and 78 % re spec tively at 110 V AC in put.
Volt age reg u la tion
:
5 and 15 V mod els
75 and 200 V mod els
Load 0 - 100%
:
10 mV (with ext.sense)
200 mV
Line 185 - 264 V AC
:
10 mV
150 mV
Rip ple + noise
:
5 mVrms, max. 20 mV p-p 70 mVrms, 100 mV p-p (BW = 20 MHz)
Stability
:
5.10
–4
dur ing 8 hours un der con stant con di tions af ter 1 hr warm up.
Temp. co ef fi cient
:
1.10
–4
per °C
Out put im ped ance
:
Max. 0.1 Ohm up to 100 kHz, ex cept
150
SX75-75 and 200-200 max. 1 Ohm.
Re cov ery time
:
0.1 ms to re cover to within 0.1 V af ter a
50-100% load step. Max. de vi a tion 0.4 V.
0.6 ms / 1.2 V for 75 V and 200 V mod els.
Am bi ent tem per a ture
:
Stor age : −40 to + 85 °C
Op er at ing : −20 to + 50 °C, de rate cur rent
lin early to 20% from 50 to 75 °C.
Temp. pro tec tion
:
Overtemperature pro tected.
Trans former with split bob bin pro vides 4 kV
di elec tric strength be tween in put and out put.
Tem per a ture de rat ing
Volt age range
Max. cur rent Model
3.5
-
6 V
13
A
75SX5
3.5
-
6 V
26
A
150SX5
6
-
15 V
5
A
75SX15-15
6
-
15 V
10
A
150SX15-15
12
-
30 V
2.5
A
75SX15-15
12
-
30 V
5
A
150SX15-15
15
-
75 V
2
A
150SX75-75
30
-
150 V
1
A
150SX75-75
35
-
200 V
0.6
A
150SX200-200
70
-
400 V
0.3
A
150SX200-200
+ and – 6 to 15 V
2.5
A
75SX15-15
+ and – 6 to 15 V
5
A
150SX15-15
+ and – 15 to 75 V
1
A
150SX75-75
+ and – 35 to 200 V
0.3
A
150SX200-200
3.5
-
6 V
13
A
ST150
6
-
15 V
5
A
3.5
-
6 V
13
A
ST150
12
-
30 V
2.5
A
3.5
-
6 V
13
A
ST150
+ and – 6 to 15 V
2.5
A
Spec i fi ca tions:
