Powersolve SM1500 Series User Manual
Page 5
SM1500
Rev. Sept. 2012
SPECIFICATIONS
Page 1 - 5
Typical Applications
• Solar inverter testing, PV-Simulation
• Lasers
• Driving PWM-controlled DC-motors
• Semiconductor burn-in & processing
• Controlled battery (dis)charging
• Accurate current sources
• Car test systems
• Component device testing
• Aerospace and military equipment
• ATE in industrial production lines
In creased
Out put Power
The conservatively rated unit
allows to deliver extra output with
the same reliability.
At some derating, either the maximum output
voltage or the maximum output current can be
increased by about 10%.
• Order Code - P069
Available Options
High speed
pro gram ming
A 10 to 20 times higher
programming speed (down to
0.2 ms rise time at full load)
and lower output capacitance.
Excellent for laser applications, test systems or
as current source with low parallel capacitance
as used in plasma chambers.
• Order Codes :
SM 15-100 P210 - SM 70-22 P214
SM 35-45 P211 - SM 120-13 P215
SM 52-30 P212 - SM 300-5 P216
SM 52-AR-60 P213 - SM 400-AR-8 P217
Sequencer
Arbitrary Waveform generator or
standalone automation.
The sequencer is integrated in
the Ethernet controller.
• Order Code - P177
High Volt age Isolation
A higher output isolation
allows series operation up to
1000V.
• Order Code - P089
Dig i tal Volt age and
Cur rent Set ting
Reliable, longlife digital encoders
can be implemented at the front
panel. Includes total front panel
lock (also for CV/CC-knobs) and
a coarse or fine pitch adjustment depending on
the turning speed.
• Order Code - P220
Se cured Volt age
and Cur rent Set ting
For a maximum
security,the CV/CC
settings can be adjusted
with a screwdriver only and are protected
with a plastic cap from accidental
adjusting.
• Order Code - P001
Soft ware Con trol and
In ter faces
Factory installed
programming interfaces:
• Ethernet controller (incl.sequencer)
- P177
• RS232 controller
- P183
• IEEE488 controller
- P184
• ISO AMP CARD - isolated analog
- P218
• PROFIBUS controller
- P273
• CANBUS controller
- P274
0,4ms
Two-Quad rant
Out put: Power sink
Two quadrant operations
maintains the output
voltage constant
regardless the output power is positive or
negative. Ideal for PWM-speed controlled
DC-motors and ATE systems.
• Order Codes :
SM 15-100 P202 - SM 52-AR-60 P205
SM 35-45 P203 - SM 70-22 P206
SM 52-30 P204
Note: 1. Down load spe cial datasheet about High Speed Pro gram., Power Sink and Bat tery Charg ing from
2. There is only room for one of the in ter faces in a unit (P177, P183, P184, P218, P273 or P274).
