SM1500

Page 1 - 4

SPECIFICATIONS

Rev. Sept. 2012

In su la tion
1

in put / out put

creepage / clear ance

in put / case
out put / case

3750 Vrms (1 min.)

8 mm

2500 Vrms

600 V DC

Safety

cTUVus / EN 60950 / EN 61010

EMC

Power Sup ply Stan dard

Ge neric Emis sion
Ge neric Im mu nity

EN 61204-3,

Emis sion: res i den tial, light in dus trial en vi ron ment (CISPR22-Class

B

)

Im mu nity: in dus trial en vi ron ment

EN 61000-6-3, res i den tial, light in dus trial en vi ron ment (EN 55022

B

)

EN 61000-6-2, in dus trial en vi ron ment

Op er at ing Tem per a ture at full
load

− 20 to + 50 °C

de rate out put to 75% at 60 °C

Hu mid ity

max. 95% RH, non con dens ing, up to 40 °C
max. 75% RH, non con dens ing, up to 50 °C

Stor age tem per a ture

− 40 to + 85 °C

Ther mal pro tec tion

Out put shuts down in case of in suf fi cient cool ing

MTBF

500 000 hrs

Hold-Up time

V

out

= 100%,

I

out

= 100%

V

out

= 85%,

I

out

=

100

%

V

out

= 100%,

I

out

= 50%

@ 230 V AC in put

16 ms
20 ms
36 ms

(time till DC-fail = 1)

Turn on de lay

af ter mains switch on

480 ms @ 230 V AC, 700 ms @ 115 V AC

In rush cur rent

27 A@115 V AC, 22 A@230 V AC

Se ries op er a tion

max. to tal volt age
Mas ter / Slave op er a tion

600 V

yes

Par al lel op er a tion

max. to tal cur rent
Mas ter / Slave op er a tion

no limit

max. 4 units (in clud ing mas ter)

Re mote sens ing

max. volt. drop per load lead

2 V

Lim its Volt age

ad just range

Cur rent

ad just range

0 - 102%
0 - 102%

Po ten ti om eters & Encoders

front panel con trol with knobs

res o lu tion

screw driver ad just ment
dig i tal encoders

stan dard

0.03 %

Op tion P001 (at front panel)

Op tion P220

SM 15-100

SM 35-45

SM 52-30

SM 52

-

AR

-

60

SM 70-22

SM 120-13

SM 300-5

SM 400

-

AR

-

8

Me ters

scale

volt age

scale

cur rent

ac cu racy read out put

read limit set ting
(d = digit)

3.5 digit

0 - 15.00 V
0 - 100.0 A

0.5% + 2 d

2% + 2 d

3.5 digit

0 - 35.0 V
0 - 45.0 A

0.5% + 2 d

2% + 2 d

3.5 digit

0 - 52.0 V
0 - 30.0 A

0.5% + 2 d

2% + 2 d

3.5 digit

0 - 52.0 V
0 - 60.0 A

0.5% + 2 d

2% + 2 d

3.5 digit

0 - 70.0 V
0 - 22.0 A

0.5% + 2 d

2% + 2 d

3.5 digit

0 - 120.0 V
0 - 13.00 A

0.5% + 2 d

2% + 2 d

3.5 digit

0 - 300 V

0 - 5.00 A

0.5% + 2 d

2% + 2 d

3.5 digit

0 - 400 V

0 - 8.00 A

0.5% + 2 d

2% + 2 d

Mount ing

Stack ing of units al lowed, air flow is from left to right.

In put Con nec tor

IEC320/C20, EN 60320/C20

Out put Ter mi nals

M8 bolts

Pro gram ming con nec tor

15 pole D-con nec tor at rear panel (FE MALE)

Cool ing

au dio noise level

air flow

Low noise blower, fan speed adapts to tem per a ture of in ter nal heatsink.

ca.45 dBA at full load, 25 °C am bi ent tem per a ture, 1 m dis tance

ca. 50 dBA at full load, 50 °C am bi ent tem per a ture, 1 m dis tance

from left to right

En clo sure

de gree of pro tec tion

IP20

Di men sions

be hind front panel: h x w x d
front panel: h x w

89 x 442 x 365 mm (feet re moved)

89 x 483 mm (19", 2 U)

Weight

9.9 kg
