Industrial Power Supplies
Features
• Installed on DIN rail TS35/7.5 or 15
• Universal AC Input 88 - 264Vac
• Short Circuit / Overvoltage / Overload Protections
• Cooling by Free Air Convection
• High Efficiency, Long Life and High Reliability
• Operating Temperature range -20°C to +70°C
• True DC OK Signal Output
• UL508 listed, UL1310 Class 2 Power Unit / LPS pass
Input Voltage 88-264VAC full range, 47-63Hz / 124-370VDC
Power Factor >0.98 @ 115VAC / >0.92 @ 230VAC at full load (PDN100 only)
AC Input Current (typ.) PDN10: 0.23A @ 115VAC / 0.17A @ 230VAC
PDN20: 0.45A @ 115VAC / 0.32A @ 230VAC
PDN40: 0.80A @ 115VAC / 0.40A @ 230VAC
PDN60: 1.3A @ 115VAC / 0.60A @ 230VAC
PDN100: 1.1A @ 115VAC / 0.55A @ 230VAC
Inrush Current PDN10: 15A @ 115VAC / 30A @ 230VAC cold start
PDN20: 20A @ 115VAC / 40A @ 230VAC cold start
PDN40, PDN60, PDN100: 30A @ 115VAC / 60A @ 230VAC cold start
Leakage Current <1mA @ 230VAC
Output Voltage See Table
Output Current See Table
Overload Protection >102% of rated output power. Constant current limiting, recovers automatically when fault removed
Overvoltage Protection 115-150% rated output voltage. Output latches off
Operating Temperature Range -20°C to +70°C (with derating)
Operating Humidity
20-90% RH non-condensing
Storage Temperature Range -40°C to +85°C
Temperature Coefficient ±0.03%/°C (0-50°C)
Vibration 10-500Hz, 2G 0.5oct/min, period for 60 mins, along X,Y & Z axis
Safety Standards UL508, TUV EN60950-1, UL1310 NEC class 2 compliant
Withstand Voltage I/P-O/P: 4242VDC, I/P-FG: 2121VDC for 1 min.
Isolation Resistance I/P-O/P, I/P-FG, O/P-FG: 100MΩ / 500VDC
EMI Conduction & Radiation EN55022: 2006 Class B, EN61204-3: 2000, EN61000-6-3: 2007
Harmonic Current EN61000-3-2, 3: 2006
EMS Immunity EN55024, EN61204-3: 2000, EN61000-6-1: 2007 (EN61000-4-2, 3, 4, 5, 6, 8, 11)
DC OK Signal PDN10 & PDN20: Open Collector max. 40mA
PDN40, PDN60, PDN100: Relay Contact (24VDC/1A, 120VAC/1A)
Cooling Free Air Convection
Dimensions PDN10, PDN20: 23(W) x 90(H) x 99(D) mm
PDN40, PDN60: 40(W) x 90(H) x 99(D)mm
PDN100: 55(W) x 90(H) x 99(D)mm
Weight PDN10: 0.13Kg
PDN20: 0.14Kg
PDN40: 0.28Kg
PDN60: 0.30Kg
PDN100: 0.40Kg
Electrical Specification
PDN10, 20, 40, 60, 100 Series
10 - 96W DIN Rail Power Supply
Single Output
