Note:
CONVECTION COOLING:
Maximun output power 90 Watts with convection cooling, derate outputs by 25% under these conditions.
PEAK CURRENT: Peak output currents of 125%, lasting <30 seconds with a maximum of 10% duty cycle can be taken,
subject to maximum 150 Watts peak load.
RIPPLE & NOISE: Maximum peak to peak noise expressed as a percentage of output voltage, 20 MHz bandwidth, input at nominal line voltage,
0.1uF and 47uF capacitor on outputs.
LOAD REGULATION: Load test conditions are from minimum, 50% and 100% load conditions on each output.
*Minimum loading of 10% required on all outputs, to achieve regulation specified.
MODEL OUTPUT 1 OUTPUT 2 OUTPUT 3 OUTPUT 4 TOTAL REGULATION
PPS120P-10 5V 24A ±3%
PPS120P-11 12V 10A ±3%
PPS120P-12 15V 8A ±3%
PPS120P-13 24V 5A ±3%
PPS120P-14 48V 2.5A ±3%
PPS120P-16 56V 2.2A ±3%
PPS120P-18 3.3V 24A ±5%
PPS120P-20* +5V 12A +12V 5A ±5% both outputs
PPS120P-21* +5V 12A +24V 2.5A ±5% both outputs
PPS120P-22* +5V 12A +48V 1.25A ±5% both outputs
PPS120P-23* +12V 6A +48V 1A ±5% both outputs
PPS120P-24* +12V 4A +56V 1.3A ±5% both outputs
PPS120P-25* +3.3V 12A +12V 7A ±5% both outputs
PPS120P-30* +5V 12A +12V 4.5A -5V 0.6A O/P 1&2 ±5%, O/P 3 ±10%
PPS120P-31* +5V 12A +12V 4.5A -12V 0.6A O/P 1&2 ±5%, O/P 3 ±10%
PPS120P-32* +5V 12A +15V 3.5A -15V 0.6A O/P 1&2 ±5%, O/P 3 ±10%
PPS120P-32A* +5V 12A +15V 2A -15V 2A O/P 1&2 ±5%, O/P 3 ±10%
PPS120P-33* +5V 12A +15V 4A -5V 0.5A O/P 1&2 ±5%, O/P 3 ±10%
PPS120P-34* +5V 12A +15V 3.5A -12V 0.7A O/P 1&2 ±5%, O/P 3 ±10%
PPS120P-35* +5V 11A +24V 2.5A -12V 0.6A O/P 1&2 ±5%, O/P 3 ±10%
PPS120P-36* +5V 11A +12V 5A -12V 1A O/P 1&2 ±5%, O/P 3 ±10%
PPS120P-37* +12V 6.5A +1.8V 6A -12V 2A O/P 1&2 ±5%, O/P 3 ±10%
PPS120P-40* +5V 12A +12V 4.5A -12V 0.5A -5V 0.5A O/P 1&2 ±5%, O/P 3&4 ±10%
PPS120P-41* +5V 12A +12V 4A -5V 1A -12V 1A O/P 1&2 ±5%, O/P 3&4 ±10%
PPS120P-42* +5V 12A +12V 3A -15V 1A +15V 1A O/P 1&2 ±5%, O/P 3&4 ±10%
PPS120P-42A +5V 10A +15V 3A -15V 1A +12V 1A O/P 1&2 ±5%, O/P 3&4 ±10%
PPS120P-43* +5V 8A +12V 3.5A -12V 1A -15V 2A O/P 1&2 ±5%, O/P 3&4 ±10%
PPS120P-44* +5V 8A +12V 2A -12V 1A +48V 1A O/P 1&2 ±5%, O/P 3&4 ±10%
PPS120P-45* +5V 8A +12V 2A -12V 1A +24V 2A O/P 1&2 ±5%, O/P 3&4 ±10%
PPS120P-46* +5V 9.6A +12V 1A -12V 2A +36V 1A O/P 1&2 ±5%, O/P 3&4 ±10%
