EST150
Page 1 - 2 SPECIFICATIONS Rev. Sept. 2012
10 V out put 20 V out puts
Out put
volt age
cur rent 0 - 10 V
0 - 5 A
0 - 20 V
0 - 2.5 A
In put
AC sin gle phase, 48 - 62 Hz
In put cur rent @ 230 V AC
power fac tor, 110 / 230 V AC
full load
in ter nal fuses
standby in put power (V o =I o =0)
standby in put power (V
o
=V
max
)
90 - 265 V
1 A
0.99 / 0.83
4 AT
12 W
15 W
Ef fi ciency
AC 230 V in put, full load
AC 110 V in put, full load 81 %
78 %
Reg u la tion
Load 0 - 100% CV
Line 90 - 265 V AC CV
6 mV
0.2 mV
5 mV
0.5 mV
Load 0 - 100% CC
Line 90 - 265 V AC CC
1 mA
0.2 mA
0.5 mA
0.1 mA
Rip ple + noise (@ full load)
rms (BW=300 kHz) CV
p-p (BW=20 MHz) CV
rms (BW=300 kHz) CC
p-p (BW=20 MHz) CC
0.5 mV
8 mV
0.5 mA
4 mA
0.5 mV
8 mV
0.25 mA
1 mA
Temp. coeff., per °C CV
CC 5.10
-5
10.10
-5
Sta bil ity af ter 1 hr warm-up
dur ing 8 hrs CV
CC
t amb = 25 ± 1 °C, V in = 230 V AC
10.10
-5
10.10
-5
Track ing ac cu racy 0.5 %
In di ca tors (front panel) CV-mode, CC-mode, out put On/Off, Track ing On/Off
Con trols (front panel) Mains on/off, CV- and CC-potmeter, Dis play-Set tings but ton,
Out put On/Off, Track ing On/Off
10 V out put 20 V out puts
Re cov ery time
re cov ery within
di/dt of load step
out put volt age
time, @ 50 - 100% load step
max. de vi a tion
@ 230 V AC in put volt age 100 mV
125 mA/µs
9 V
100 µs
200 mV
50 mV
75 mA/µs
18 V
100 µs
200 mV
Out put im ped ance
CV, 0-100 kHz < 250 mOhm < 250 mOhm
Pul sat ing load
max. tol er a ble AC com po nent
of load cur rent
f > 1 kHz
f < 1 kHz
2 A rms
5 A peak
2 A rms
2.5 A peak
