Powersolve PPS150LBP Series - Manual (Page 2)

Powersolve Electronics Ltd. Units 8A, Arnhem Road, Newbury, RG14 5RU. England
Tel:01635 521858 Fax: 01635 523771 Email: [email protected]
www.powersolve.co.uk
AC-DC Converters
Note:
MAX POWER: 150 Watts convection cooled, 195 Watts peak for <30 seconds with a maximum 10% duty cycle.
RIPPLE & NOISE: Maximum peak to peak noise expressed as a percentage of output voltage, 20 MHz bandwidth, input at nominal line voltage,
0.1uF and 47uF capacitor on outputs.
LOAD REGULATION: Load test conditions are from minimum, 50% and 100% load conditions on each output.
*Minimum loading of 10% required on all outputs, to achieve regulation specified.
MODEL OUTPUT 1 OUTPUT 2 OUTPUT 3 OUTPUT 4 TOTAL REGULATION
PPS150LBP-10 5V 30A ±3%
PPS150LBP-11 12V 12.5A ±3%
PPS150LBP-12 15V 10A ±3%
PPS150LBP-13 24V 6.26A ±3%
PPS150LBP-14 48V 3.12A ±3%
PPS150LBP-15 3.3V 30A ±3%
PPS150LBP-20* +5V 17A +12V 7A ±5% both outputs
PPS150LBP-21* +5V 17A +24V 3.7A ±5% both outputs
PPS150LBP-22* +5V 17A -5V 17A ±5% both outputs
PPS150LBP-23* +12V 7A -12V 7A ±5% both outputs
PPS150LBP-24* +15V 5A -15V 5A ±5% both outputs
PPS150LBP-25* +3.3V 17A +12V 8A ±5% both outputs
PPS150LBP-26* +5V 17A +48V 1.8A ±5% both outputs
PPS150LBP-30* +5V 17A +12V 7A -5V 1A O/P 1&2 ±5%, O/P 3 ±10%
PPS150LBP-31* +5V 17A +12V 7A -12V 1A O/P 1&2 ±5%, O/P 3 ±10%
PPS150LBP-32* +5V 17A +15V 5A -15V 1A O/P 1&2 ±5%, O/P 3 ±10%
PPS150LBP-33* +5V 24A +15V 3A -5V 1A O/P 1&2 ±5%, O/P 3 ±10%
PPS150LBP-34* +5V 22A +15V 3A -12V 1A O/P 1&2 ±5%, O/P 3 ±10%
PPS150LBP-35* +5V 15A +24V 3A -12V 1A O/P 1&2 ±5%, O/P 3 ±10%
PPS150LBP-36* +5V 10A +12V 8A -12V 1A O/P 1&2 ±5%, O/P 3 ±10%
PPS150LBP-37* +5V 15A +12V 6A +24V 1A O/P 1&2 ±5%, O/P 3 ±10%
PPS150LBP-38* +5V 10A +12V 4A +48V 1.2A O/P 1&2 ±5%, O/P 3 ±10%
PPS150LBP-40* +5V 17A +12V 6A -12V 1A -5V 1A O/P 1&2 ±5%, O/P 3&4 ±10%
PPS150LBP-41* +5V 17A +12V 3.5A -12V 2A -5V 2A O/P 1&2 ±5%, O/P 3&4 ±10%
PPS150LBP-42* +5V 17A +12V 3.5A -15V 2A +15V 2A O/P 1&2 ±5%, O/P 3&4 ±10%
PPS150LBP-43* +5V 10A +12V 4A -15V 2A -12V 2A O/P 1&2 ±5%, O/P 3&4 ±10%
PPS150LBP-44* +5V 10A +12V 2A -12V 2A +48V 1.5A O/P 1&2 ±5%, O/P 3&4 ±10%
PPS150LBP-45* +5V 10A +12V 3A -12V 2A +24V 2A O/P 1&2 ±5%, O/P 3&4 ±10%
PPS150LBP-46* +3.3V 20A +5V 10A +12V 2A -12V 1A O/P 1&2 ±5%, O/P 3&4 ±10%
PPS150LBP-47* +3.3V 10A +5V 10A +12V 4A -12V 1A O/P 1&2 ±5%, O/P 3&4 ±10%
