2 date:01/22/13 #:125-9401
ENG - This product was designed to be installed on wood stud, solid concrete or cinder block walls. Before in-
stalling make sure the supporting surface will support the combined load of the equipment and hardware. Screws
must be tightly secured. Do not overtighten screws or damage can occur and product may fail. Never exceed
the Maximum Load Capacity. Always use an assistant or mechanical lifting equipment to safely lift and position
equipment. This product is intended for indoor use only. Use of this product outdoors could lead to product failure
or personal injury. For support please call customer care at 1-800-865-2112.
WARNING
Symbols
WARNING
#
Skip to step.
Display
center.
x3
Screws must get at
least three full turns
and fit snug.
Do not over tighten screws
1
2
To properly tighten screws: Tighten until screw head
makes contact, then tighten another 1/2 turn. Do not
overtighten screws.
+1/2
4
3
