Peerless-AV VPM25-J - Installation - Manual

ISSUED: 05-19-04 SHEET #: 081-9032-3 02-14-06
For customer service call 1-800-729-0307 or 708-865-8870. Visit the Peerless Web Site at www.peerlessindustries.com
1 of 5
Read instruction sheet before you start installation and assembly.
Maximum Load Capacity:
50 lb (22.7 kg)
Models: VPM 25-J, VPM 25-JS,
SVPM 25-J, SVPM 25-JS
DVD/DVR/VCR Mount for
Jumbo
® Mount
Installation and Assembly -
DVD/DVR/VCR MOUNT
JUMBO MOUNT
WIDTH (W) HEIGHT (H) MAXIMUM MINIMUM
13.25" - 17.25" 1.5" - 2.75" 17.25" x 2.50" 13.25" x 1.5"
(337 mm - 438 mm) (38 mm - 70 mm) (438 mm x 64 mm) (337 mm x 38 mm)
INSIDE DIMENSIONS MEDIA PLAYER DIMENSIONS
Installing a DVD/DVR/VCR Mount to a Jumbo ® Mount with Threaded Holes in Center of Tray .................... page 3
Installing a DVD/DVR/VCR Mount to a Jumbo Mount with Slots in Center of Tray ........................................ page 3
Installing a Single DVD/DVR/VCR Mount ........................................................................................................... page 4
Installing Multiple DVD/DVR/VCR Mounts .......................................................................................................... page 5
