Peerless-AV DS334 - Installation User Manual
Parts list

ISSUED: 03-05-09 SHEET #: 125-9049-1
1 of 4
Visit the Peerless Web Site at www.peerlessmounts.com
For customer service call 1-800-729-0307 or 708-865-8870.
Model: DS334
Installation and Assembly - Plasma PC Mount Bracket
Qty.
Part #
Description
A
mount adapter
1
201-1196
B
mount attachment bracket
1
201-1198
C
clamp bracket
2
201-1199
D
M5 x 10 mm socket pin serrated washer head screw
8
510-1126
E
M6 x 10 mm socket pin serrated washer head screw
4
510-1066
F
M10 x 15 mm penta-pin screw
8
520-9263
G
4 mm security allen wrench
1
560-9646
H
penta-pin tool
1
520-9260
I
rubber pad (not shown)
12
590-1159
Parts List
Before you start check the parts list to insure all of the parts shown are included.
Note: Read instruction sheet before you start installation and assembly.
D
E
F
G
H
A
B
C
