Peerless-AV PCC-S - Installation User Manual
Page 2
2 of 24
ISSUED: 04-23-08 SHEET #: 120-9046-3 09-28-12
Visit the Peerless Web Site at www.peerless-av.com
For customer care call 1-800-865-2112
Note: Read entire instruction sheet before you start installation and assembly.
Table of Contents
Parts List.................................................................................................................................................................................3
Placement and Orientation of Covers.....................................................................................................................................4
Installation to Wood Stud Or Drywall ......................................................................................................................................5
Installation to Concrete and Cinder Block ..............................................................................................................................6
Cable Management ................................................................................................................................................................7
Tools Needed for Assembly
• phillips screwdriver
• drill
• 1/4" drill bit for wood stud wall
• level
• Do not begin to install your Peerless product until you have read and understood the instructions and warnings
contained in this Installation Sheet. If you have any questions regarding any of the instructions or warnings, please
call Peerless customer care at 1-800-865-2112.
• This product should only be installed by someone of good mechanical aptitude, has experience with basic building
construction, and fully understands these instructions.
• Tighten screws fi rmly, but do not overtighten. Overtightening can damage the items, greatly reducing their holding
power.
• This product was designed and intended to be mounted to the following supporting surfaces checked below with
the hardware included in this product as specifi ed in the installation sheet. To mount this product to an alternative
supporting surface, contact Peerless customer care at 1 800 865-2112.
• This product was designed to be installed on the following wall construction only;
WALL CONSTRUCTION
ADDITIONAL HARDWARE REQUIRED
x Wood
Stud
None
x
Wood
Beam
None
x
Solid
Concrete
None
x
Cinder
Block
None
x
Metal
Stud
None
Brick
Contact
Customer
Service
x
Drywall
None
Other or unsure?
Contact Customer Service
WARNING
