DATA SHEET
Gutter
“Duro-Last” and “EXCEPTIONAL” are registered marks owned by Duro-Last Roofing, Inc. Revised 8/30/2012
Description:
Gutters feature four box-style profiles in three sizes
each.
Support straps are provided based on 30”
centers.
Front edge of gutter is 2” lower than the back
edge.
Internal splice plates eliminate the need to
completely rivet sections together. Use
compatible sealant.
Riveted inside and outside miters can be
fabricated to any angle.
Roof flanges can be bent to accommodate
various roof pitches or eliminated altogether.
Custom sizes and profiles are available.
Contact Duro-Last ® or EXCEPTIONAL ® Metals to
request a color chart, samples and information
regarding custom metals and finishes.
Energy Efficiency:
LEED ® and ENERGY STAR ® compliant; Recyclable.
Installation:
1. Install in accordance with Duro-Last detail
drawings #2091 and #3025.
2. Any deviation from the requirements set forth in
the detail drawings must be pre-approved, in
writing, by the EXCEPTIONAL Metals Technical
Department.
Warranty:
Duro-Last offers a wide range of warranty coverage for
EXCEPTIONAL Metals products when used with the
Duro-Last roofing system, including paint and finish.
Technical Services:
Product samples, detail sheets, color chips, and a color
chart are available for your submittal package. For
assistance with questions or submittals, contact your
local representative or call EXCEPTIONAL Metals.
Material Gauge Finish
Aluminum .040 / .050 Mill or Kynar ®
Stainless Steel 24-gauge N/A
Bonderized Steel 24-gauge N/A
Galvalume 24-gauge Mill or Kynar ®
Copper 16 oz. Mill
DX-Style EX-Style
MX-Style
LX-Style
Note: Gutter size to be determined by
the contractor or design professional.
