DATA SHEET
Fascia Cover
“Duro-Last” and “EXCEPTIONAL” are registered marks owned by Duro-Last Roofing, Inc. Revised 8/30/2012
Description:
The 1- 3/4” and 4” Fascia Cover provide a professional
finish without perimeter welding. The fascia cover is to
be used in conjunction with the Duro-Last
® vinyl 1- 3/4”
and 4” fascia bar.
Manufactured from various metals (see chart
below) in
10’ lengths; 1-3/4” and 4” widths.
End-notched to provide trouble-free piece-to-
piece docking.
Ready-to-assemble inside and outside corners
are available.
Contact Duro-Last or EXCEPTIONAL ® Metals to
request a color chart, samples and information
regarding custom metals and finishes.
Energy Efficiency:
LEED
®
and ENERGY STAR
®
compliant; Recyclable.
Installation:
1. A wood nailer is required if 1” or greater of
insulation is used.
2. This nailer should be attached to the wall in
accordance with ANSI/SPRI ES-1 3.9.
3. Install in accordance with Duro-Last detail
drawings #3110, #3500, and #3510.
4. Any deviation from the requirements set forth in
the detail drawings must be pre-approved, in
writing, by the EXCEPTIONAL Metals Technical
Department.
Codes and Standards:
ANSI/SPRI ES-1 Compliant with 24-gauge
Galvalume and .040 aluminum cover.
Meets TAS 111-95 Test with 4” cover.
FM Approved.
Warranty:
Duro-Last offers a wide range of warranty coverage for
EXCEPTIONAL Metals products when used with the
Duro-Last roofing system, including paint and finish.
Technical Services:
Product samples, detail sheets, color chips, and a color
chart are available for your submittal package. For
assistance with questions or submittals, contact your
local representative or call EXCEPTIONAL Metals.
Material Gauge Finish
Aluminum .040 Mill or Kynar ®
Stainless Steel 24-gauge N/A
Bonderized Steel 24-gauge N/A
Galvalume 24-gauge Mill or Kynar ®
Copper 16 oz. Mill
1- 3/4” Fascia Cover
4” Fascia Cover
