USB-to-Serial Adapter User’s Manual Using configuration utilities
Rev 1.01 (February 2007) Page 19
Step Procedure Description
 Flow control

Step 10 Press the Advanced button. The Advanced Options dialog box opens.
Figure 19 - Windows XP/2000 USB serial port, Advanced settings box
Step Procedure Description

Step 11 Use the drop down box to select the port
whose settings you wish to change.
Click Cancel to return to the Port Settings
tab.

Step 12 Click the Driver tab to view the driver
information and update the driver.
The USB Serial Driver properties dialog
box displays.
Figure 20 - Windows XP/2000 USB serial port properties, Driver box
Step Procedure Description

Step 13 You have several options:
Figure 20 illustrates the
USB Serial Ports Driver
dialog, which lets you view
the driver details and
update, roll back (XP only),
and uninstall the driver:
