1
About the IE-iMcV-MultiWay
The IE-iMcV-MultiWay is an SNMP manageable modular device providing two fixed
10/100/1000Base-T copper ports and 2 SFP ports. The SFP ports support fiber or
copper SFPs. As a plug and play device, the IE-iMcV-MultiWay provides several
distinct modes of operation to support a wide range of applications. The IE-iMcV-
MultiWay provides OAM functionality with 802.3ah (LINK-OAM ah) and 802.1ag
(SERVICE-OAM ag) supported on each port
. It supports jumbo frame sizes of up to
10,240 bytes as well as AutoCross on the copper ports. As an Industrial Ethernet
device, it supports an extended temperature range of -40°C to +85°C. A console
port and a DIP Switch bay provide configuration options.
The IE-iMcV-MultiWay module is a single-wide module. It can be installed in the
following chassis:
• MediaChassis series
• IE-MediaChassis series
• iMediaChassis series
The IE-iMcV-MultiWay requires two small form-factor (SFP) modules which provide
greater flexibility in the network environment. The hot-swappable nature of the SFPs,
available in dual strand for Multi Mode and Single Mode, and single strand fiber types
for Single Mode, allow for easy configuration and future upgrading as network
demands evolve. The SFP modules must be MSA-compliant and both DDMI and
non-DDMI are supported
. The fiber SFP can support 100Mbps or 1000Mbps; while
the copper SFPs support 10/100/1000Mbps and 1000Mbps.
SFPs are sold separately by IMC Networks and meet Class 1 Laser Safety Standard.
IE-iMcV-MultiWay Features and Configuration
The IE-iMcV-MultiWay offers a full feature set including Auto Negotiation, Selective
Advertising, AutoCross, VLANs, SNMP management, loopback testing and OAM. Unit
software updates can be downloaded through TFTP or iView
2 (iConfig view).
IE-iMcV-MultiWay features include:
• SNMP manageable
• OAM AH
o IEEE 802.3ah Link OAM for per port monitoring (OAM AH)
