Section 3 - Quick Start Guide
Page 9 of 45 Document Number: USR60x-0812m
www.bb-elec.com/
www.bb-europe.com/
Quick Start Guide
The following Quick Start Guide outlines the basic steps to get your
USR60x Converter up and running:
1. Check for included items
• 2 or 4 port industrial USB to serial converter
• Two meter USB cable
• Panel mount adapters
• DIN rail mount adapter
• Driver CD
• This quick start guide
2. Install the driver software (see " Installing the Driver " on page 13)
• The CD contains a driver installation program. Install the drivers
before connecting the converter to your PC.
• Put CD into drive. The installation program should launch
automatically.
• Follow the prompts
3. Mount the converter (DIN rail or panel mount)
• DIN Rail
•
Locate DIN rail kit
• Mount on back of converter using screws
• Clip to a DIN rail
• Panel mount:
•
Locate the panel mount kit
• Mount brackets to converter using screws
• Mount in panel
4. Connect power (see " Connecting Power " on page 18):
• USR602: Plug USB cable from PC into converter
