Section 7 - Specifications
Page 32 of 45 Document Number: USR60x-0812m
www.bb-elec.com/
www.bb-europe.com/
Product Specifications
Category Specification
Models USR602, USR604
User documentation User manual: on CD and B&B website
Data sheet: on B&B website
Quick Start Guide: Printed
Software Included on CD
Operating Systems Supported Server 2008 R2, Windows 7, Windows 7 x64, Windows Server 2008, Windows Server 2008
x64, Windows Vista, Windows Vista x64, Windows Server 2003, Windows Server 2003 x64,
Windows XP, Windows XP x64, Windows 2000
Dimensions USR602: 5.440in x 1.4in x 3.5in (13.8cm x 3.54cm x 8.75cm)
USR604: 8.00in x 1.4in x 4.70in (20.30cm x 3.54cm x 12.0cm)
Protocols USB 1.1 and 2.0
Speed 1.5Mbps, 12 Mbps, 480 Mbps
Isolation 2 kV port to port
Upstream connector Type B high retention (15 Newton / 3.4 lbs withdrawal force)
Serial connector One DB-9M connector for each serial port
Serial modes R-232 (DTE), RS-485 two-wire, RS-485 four-wire
RS-232 lines supported TD, RD, RTS, CTS, DTR, DSR, DCD, GND
RS-422/485 lines (4-wire) TDA(-), TDB(+), RDA(-), RDB(+), GND
RS-485 lines (2-wire) DATA A(-), DATA B(+), GND
RS-422/485 HS loopback Loop back RTS to CTS, DTR to DSR/DCD
Baud rate
(kbps)
300, 600, 1200, 1800, 2400, 4800, 7200, 9600, 14400, 19200, 38400, 57600, 115200,
230400, 460800, 921600
Data bits 5, 6, 7, 8
Parity none, odd, even
Stop bit(s) 0, 1, 2
Switches Quad DIP switch for user hardware selectibility per port
Driver WHQL
Power supply requirement 10VDC to 48VDC
Power supply connectors Three position removable terminal block, threaded barrel jack with center +
Operating temperature -40C to 80C
Storage temperature -40C to 85C
Humidity 5% to 90% non-condensing
LED indicators Power - continuously on if powered via external supply or USB bus
Four communication LEDs: P1 TX, P1 RX, P2 TX, P2 RX - green, blink when data present
Enclosure mounting DIN adapter, Panel mounting with mounting kit
Accessories Power supply: 12 VDC wall plug
Cables: USB cable included with product
Mounting: DIN adapter included on enclosure
