Section 4 - Software Installation
Page 15 of 45 Document Number: USR60x-0812m
www.bb-elec.com/
www.bb-europe.com/
3. When the installation is complete you can plug in the USB to Serial
Converter. When you do this, the COM ports will be assigned. It
may take up to 30 seconds to make the COM port assignments the
first time you plug in the converter.
4. The driver software is now installed.
5. To verify that the communication port has been configured:
a. Open the Control Panel
b. Click System to open the System Properties dialog box.
c. Select the Hardware tab.
d. Click Device Manager to open the Device Manager dialog box.
e. Expand Ports (COM & LPT)
USB Isolated Serial Port should be listed as one of the COM
ports.
