15
config Allows VLAN and transparency mode configurations.
accounts Allows the addition of new users.
sysdescr Allows the editing of sysName, sysDescr, and Port information
text.
unit Unit Global Setting
bw Bandwidth Limiting Controls
sfpstats Provides information about the wavelength, serial number, output
power, BER, and other useful information.
Last Gasp* The Last Gasp feature sends a trap down when the power module
fails.
*Refer to the Unit Control Settings section on page 26.
Cleandb
Entering cleandb reboots the unit with its database cleaned depending on the option
selected. Users are presented with two, sequential options, first to reset all SNMP
settings and, second, to reset all of the unit’s configuration to default. Enabling the
first option presents the second. Resetting the unit to factory default values (option
two) will delete all custom IP and VLAN settings.
Downloading Files
Firmware for the IE-MiniFiberLinX-II can be downloaded from a central server via
TFTP protocol. Initiate this download via serial configuration or Telnet session. To
download a file, type download and press Enter to be taken to the Download a file
screen. This screen displays the IP Address of the TFTP server and the name of the
file to be downloaded. The TFTP server should be open. Make sure the IP Address
and the name of the file are correct in the Current Values section of the Main
Configuration screen. These are changed by entering I from the Main Configuration
screen. Press Enter to start downloading the file.
Viewing Port Statistics
To view port statistics on the IE-MiniFiberLinX-II, enter ifstats. This will open a screen
displaying information on packets received and transmitted as defined by MIB-II
standard RFC 1213.
Pressing the Space Bar will refresh the data on the screen.
