Off
(lower LED)
The port is disconnected or not operating
at speed of 1000M
P1 ~ P8
Green
(Upper LED)
Network device detected
Blinking
(Upper LED)
Network is active
Off
(Upper LED)
No device attached
Yellow
(Lower LED)
The port is operating in full-duplex mode
Blinking
(Lower LED)
Data packet collision
Off
(Lower LED)
The port is in half-duplex mode or no
device attached
Ports
RJ-45 ports (Auto MDI/MDIX): The RJ-45 ports are auto-sensing for
10Base-T, 100Base-TX or 1000Base-T devices connections and Auto
MDI/MDIX.
„ RJ-45 Pin Assignments
Pin Number Assignment
1 Tx+
2 Tx-
3 Rx+
6 Rx-
