43 Adesto AT45DB161E [DATASHEET]
8782D–DFLASH–11/2012
Table 15-7. Detailed Bit-level Addressing Sequence for Standard DataFlash Page Size (528 bytes)
Note: P = Page Address Bit B = Byte/Buffer Address Bit X = Dummy Bit
Page Size = 528-bytes Address Byte Address Byte Address Byte
Additional
Dummy
Bytes Opcode Opcode
Reserved Reserved PA11 PA10 PA9 PA8 PA7 PA6 PA5 PA4 PA3 PA2 PA1 PA0 BA9 BA8 BA7 BA6 BA5 BA4 BA3 BA2 BA1 BA0
01h 0 0 0 0 0 0 0 1 X X P P P P P P P P P P P P B B B B B B B B B B N/A
02h 0 0 0 0 0 0 1 0 X X P P P P P P P P P P P P B B B B B B B B B B N/A
03h 0 0 0 0 0 0 1 1 X X P P P P P P P P P P P P B B B B B B B B B B N/A
0Bh 0 0 0 0 1 0 1 1 X X P P P P P P P P P P P P B B B B B B B B B B 1
1Bh 0 0 0 1 1 0 1 1 X X P P P P P P P P P P P P B B B B B B B B B B 2
32h 0 0 1 1 0 0 1 0 X X X X X X X X X X X X X X X X X X X X X X X X N/A
35h 0 0 1 1 0 1 0 1 X X X X X X X X X X X X X X X X X X X X X X X X N/A
50h 0 1 0 1 0 0 0 0 X X P P P P P P P P P X X X X X X X X X X X X X N/A
53h 0 1 0 1 0 0 1 1 X X P P P P P P P P P P P P X X X X X X X X X X N/A
55h 0 1 0 1 0 1 0 1 X X P P P P P P P P P P P P X X X X X X X X X X N/A
58h 0 1 0 1 1 0 0 0 X X P P P P P P P P P P P P X X X X X X X X X X N/A
59h 0 1 0 1 1 0 0 1 X X P P P P P P P P P P P P X X X X X X X X X X N/A
60h 0 1 1 0 0 0 0 0 X X P P P P P P P P P P P P X X X X X X X X X X N/A
61h 0 1 1 0 0 0 0 1 X X P P P P P P P P P P P P X X X X X X X X X X N/A
77h 0 1 1 1 0 1 1 1 X X X X X X X X X X X X X X X X X X X X X X X X N/A
79h 0 1 1 1 1 0 0 1 N/A N/A N/A N/A
7Ch 0 1 1 1 1 1 0 0 X X P P P P X X X X X X X X X X X X X X X X X X N/A
81h 1 0 0 0 0 0 0 1 X X P P P P P P P P P P P P X X X X X X X X X X N/A
82h 1 0 0 0 0 0 1 0 X X P P P P P P P P P P P P B B B B B B B B B B N/A
83h 1 0 0 0 0 0 1 1 X X P P P P P P P P P P P P X X X X X X X X X X N/A
84h 1 0 0 0 0 1 0 0 X X X X X X X X X X X X X X B B B B B B B B B B N/A
85h 1 0 0 0 0 1 0 1 X X P P P P P P P P P P P P B B B B B B B B B B N/A
86h 1 0 0 0 0 1 1 0 X X P P P P P P P P P P P P X X X X X X X X X X N/A
87h 1 0 0 0 0 1 1 1 X X X X X X X X X X X X X X B B B B B B B B B B N/A
88h 1 0 0 0 1 0 0 0 X X P P P P P P P P P P P P X X X X X X X X X X N/A
89h 1 0 0 0 1 0 0 1 X X P P P P P P P P P P P P X X X X X X X X X X N/A
9Fh 1 0 0 1 1 1 1 1 N/A N/A N/A N/A
B9h 1 0 1 1 1 0 0 1 N/A N/A N/A N/A
ABh 1 0 1 0 1 0 1 1 N/A N/A N/A N/A
B0h 1 0 1 1 0 0 0 0 N/A N/A N/A N/A
D0h 1 1 0 1 0 0 0 0 N/A N/A N/A N/A
D1h 1 1 0 1 0 0 0 1 X X X X X X X X X X X X X X B B B B B B B B B B N/A
D2h 1 1 0 1 0 0 1 0 X X P P P P P P P P P P P P B B B B B B B B B B 4
D3h 1 1 0 1 0 0 0 1 X X X X X X X X X X X X X X B B B B B B B B B B N/A
D4h 1 1 0 1 0 1 0 0 X X X X X X X X X X X X X X B B B B B B B B B B 1
D6h 1 1 0 1 0 1 1 0 X X X X X X X X X X X X X X B B B B B B B B B B 1
D7h 1 1 0 1 0 1 1 1 N/A N/A N/A N/A
