Page 20
20
4931C–AUTO–09/06
ATA6824 [Preliminary]
7.17
Fall time low-side driver
V
VBAT
= 13.5V
C
Gx
=5 nF
t
Lxf
0.5
µs
7.18
Rise time low-side driver
t
Lxr
0.5
µs
7.19
Propagation delay time,
high-side driver from high
to low
V
VBAT
= 13.5V
t
HxHL
0.5
µs
7.20
Propagation delay time,
high-side driver from low
to high
t
HxLH
0.5 + t
CC
µs
7.21
Fall time high-side driver
V
VBAT
= 13.5V,
C
Gx
= 5 nF
t
Hxf
0.5
µs
7.22
Rise time high-side driver
t
Hxr
0.5
µs
7.23
Cross conduction time
(8)
t
CC
10
µs
7.24
External resistor
R
CC
5
k
Ω
7.25
External capacitor
C
CC
5
nF
7.26
R
ON
of t
CC
switching
transistor
R
ONCC
100
Ω
7.27
Switching level of t
CC
comparator
V
swtcc
0.653
×
V
VCC
0.667
×
V
VCC
0.68
×
V
VCC
V
7.28
Short circuit detection
voltage
(9)
V
SC
3.5
4
4.5
V
7.29
Short circuit detection
time
(10)
t
SC
5
10
15
ms
8
Diagnostic Outputs DG1, DG2, DG3
8.1
Low level output current
V
DG
= 0.4V
(6)
IL
4
mA
8.2
High level output current
V
DG
= VCC – 0.4V
(6)
IH
4
mA
10. Electrical Characteristics (Continued)
All parameters given are valid for 7V
≤
VBAT
≤
18V and for –40°C
≤ ϑ
ambient
≤
150°C unless stated otherwise.
No.
Parameters
Test Conditions
Pin
Symbol
Min
Typ
Max
Unit
Type*
* Type: A = 100% tested, B = 100% correlation tested, C = Characterized on samples, D = Design parameter
Notes:
1. EN, DIR, PWM = high
2. The use of X7R material is recommended
3. For higher values, stability at zero load is not guaranteed
4. Tested during qualification only
5. Value depends on T
OSC
; function tested with digital test pattern
6. Tested during characterization only
7. Supplied by charge pump
8. See section
“Cross Conduction Time”
9. Voltage between source-drain of external switching transistors in active case
10. The short-circuit message will never be generated for switch-on time < t
sc
