16. Power-on/Reset State
When power is first applied to the device, or when recovering from a reset condition, the device will default to Mode
3. In addition, the output pin (SO) will be in a high impedance state, and a high-to-low transition on the CS pin will
be required to start a valid instruction. The mode (Mode 3 or Mode 0) will be automatically selected on every falling
edge of CS by sampling the inactive clock state.
16.1 Initial Power-up/Reset Timing Restrictions
At power up, the device must not be selected until the supply voltage reaches the V
CC
(min.) and further delay of
t
VCSL
. During power-up, the internal Power-on Reset circuitry keeps the device in reset mode until the V
CC
rises
above the Power-on Reset threshold value (V
POR
). At this time, all operations are disabled and the device does not
respond to any commands. After power up is applied and the V
CC
is at the minimum operating voltage V
CC
(min.),
the t
VCSL
delay is required before the device can be selected in order to perform a read operation.
Similarly, the t
PUW
delay is required after the V
CC
rises above the Power-on Reset threshold value (V
POR
) before the
device can perform a write (Program or Erase) operation. After initial power-up, the device will default in Standby
mode.
Table 16-1. Initial Power-up/Reset Timing Restrictions
17. System Considerations
The RapidS serial interface is controlled by the clock SCK, serial input SI and chip select CS pins. These signals
must rise and fall monotonically and be free from noise. Excessive noise or ringing on these pins can be
misinterpreted as multiple edges and cause improper operation of the device. The PC board traces must be kept to
a minimum distance or appropriately terminated to ensure proper operation. If necessary, decoupling capacitors
can be added on these pins to provide filtering against noise glitches.
As system complexity continues to increase, voltage regulation is becoming more important. A key element of any
voltage regulation scheme is its current sourcing capability. Like all Flash memories, the peak current for
DataFlash occur during the programming and erase operation. The regulator needs to supply this peak current
requirement. An under specified regulator can cause current starvation. Besides increasing system noise, current
starvation during programming or erase can lead to improper operation and possible data corruption.
Symbol Parameter Min Typ Max Units
t
VCSL
V
CC
(min.) to Chip Select low 70 µs
t
PUW
Power-Up Device Delay before Write Allowed 20 ms
V
POR
Power-ON Reset Voltage 1.5 2.5 V
