Block diagram – Rainbow Electronics W9864G6GB User Manual
Page 6
W9864G6GB
- 6 -
6. BLOCK
DIAGRAM
DQ0
DQ15
UDQM
LDQM
CLK
CKE
A10
CLOCK
BUFFER
COMMAND
DECODER
ADDRESS
BUFFER
REFRESH
COUNTER
COLUMN
COUNTER
CONTROL
SIGNAL
GENERATOR
MODE
REGISTER
COLUMN DECODER
SENSE AMPLIFIER
CELL ARRAY
BANK #2
COLUMN DECODER
SENSE AMPLIFIER
CELL ARRAY
BANK #0
COLUMN DECODER
SENSE AMPLIFIER
CELL ARRAY
BANK #3
DATA CONTROL
CIRCUIT
DQ
BUFFER
COLUMN DECODER
SENSE AMPLIFIER
CELL ARRAY
BANK #1
NOTE:
The cell array configuration is 4096 * 256 * 16
ROW DECODER
ROW DECODER
ROW DECODER
ROW DECODER
A0
A9
BS0
BS1
CS
RAS
CAS
WE
A11
