W9864G6GB
Publication Release Date: August 14, 2006
- 15 - Revision A01
12. DC CHARACTERISTICS
(V CC =2.7V~3.6V, T A = 0 to 70°C )
PARAMETER SYM. -7 ( MAX.) UNIT NOTES
Operating Current
tCK = min., tRC = min.
Active precharge command
cycling without burst
operation
1 bank operation
ICC1 80 3
Standby Current
tCK = min.,
CS = VIH
VIH/L = VIH (min.)/VIL
(max.)
CKE = VIH
ICC2 30 3
Bank: Inactive State
CKE = VIL
(Power Down
mode)
ICC2P 2 3
Standby Current
CLK = VIL,
CS = VIH
VIH/L=VIH (min.)/VIL (max.)
CKE = VIH
ICC2S 15
BANK: Inactive State
CKE = VIL
(Power Down
mode)
ICC2PS 2
No Operating Current
tCK = min.,
CS = VIH (min.)
CKE = VIH ICC3 55
BANK: Active State (4
banks)
CKE = VIL
(Power Down
mode)
ICC3P 15
Burst Operating Current (tCK = min.)
Read/Write command cycling
ICC4 145 3, 4
Auto Refresh Current (tCK = min.)
Auto refresh command cycling
ICC5 120 3
Self Refresh Current
Self refresh mode
(CKE = 0.2V)
Standard(-7) ICC6 2
mA
PARAMETER SYMBOL MIN. MAX. UNIT NOTES
Input Leakage Current
(0V ≤ VIN ≤ VCC, all other pins not under test = 0V)
II(L) -5 5 µA
Output Leakage Current
(Output disable, 0V ≤ VOUT ≤ VCCQ)
IO(L) -5 5 µA
LVTTL Output ″ H ″ Level Voltage
(IOUT = -2 mA)
VOH 2.4 - V
LVTTL Output " L ″ Level Voltage
(IOUT = 2 mA)
VOL - 0.4 V
