W9864G6GB
- 14 -
9. ABSOLUTE MAXIMUM RATING
PARAMETER SYM.
RATING
UNIT
NOTES
Input, Column Output Voltage(-7)
V
IN
, V
OUT
2.7V~3.6V
V
1
Power Supply Voltage
V
CC,
V
CCQ
-0.3
− 4.6
V 1
Operating Temperature(-7)
T
OPR
0
− 70
°C
1
Storage Temperature
T
STG
-55
− 150
°C
1
Soldering Temperature (10s)
T
SOLDER
260
°C
1
Power Dissipation
P
D
1 W
1
Short Circuit Output Current
I
OUT
50 mA
1
Note
: Exposure to conditions beyond those listed under Absolute Maximum Ratings may adversely affect the life and reliability
of the device.
10. RECOMMENDED DC OPERATING CONDITIONS
(T
A
= 0 to 70°C for -7)
PARAMETER SYM.
MIN.
TYP.
MAX.
UNIT
NOTES
Power Supply Voltage(-7)
V
CC
2.7 3.3
3.6
V
2
Power Supply Voltage for I/O Buffer(-7)
V
CCQ
2.7 3.3
3.6
V
2
Input High Voltage
V
IH
2.0 - V
CC
+0.3
V
2
Input Low Voltage
V
IL
-0.3
- 0.8 V 2
Note:
V
IH
(max.) = V
CC
/V
CC
Q+1.2V for pulse width < 5 nS, V
IL
(min.) = V
SS
/V
SS
Q-1.2V for pulse width < 5 nS
11. CAPACITANCE
(V
CC
= 2.7V~3.6V, T
A
= 25
°C, f = 1 MHz)
PARAMETER SYM.
MIN.
MAX.
UNIT
Input Capacitance
(A0 to A11, BS0, BS1,
CS
,
RAS
,
CAS
,
WE
, , CKE)
C
i1
2.5 4 pf
Input Capacitance (CLK)
C
CLK
2.5 4 pf
Input/Output Capacitance (DQ0
−DQ15)
C
o
4 6.5 pf
Input Capacitance DQM
C
i2
3.0 5.5 pf
Note
: These parameters are periodically sampled and not 100% tested
