MAX17047
ModelGauge m3 Fuel Gauge
Table 5. Device Memory Map (continued)
ADDRESS
(HEX)
REGISTER NAME
A/D
MEASURE
ALERT/
STATUS
MG m3
APP
DATA
MG m3
CELL
DATA
MG m3
CONFIG
MG m3
SAVE AND
RESTORE
MG m3
OUTPUT
POR
VALUE
READ/
WRITE
22h QResidual 10 ь ь 1E00h R/W
23h FullCapNom ь ь 07D0h R/W
24h TempNom ü 1400h R/W
25h TempLim ü 2305h R/W
26h RESERVED — —
27h AIN ü 88D0h R
28h LearnCFG ü 2603h R/W
29h FilterCFG ü 4EA4h R/W
2Ah RelaxCFG ü 203Bh R/W
2Bh MiscCFG ü 0870h R/W
2Ch TGAIN ü E3E1h R/W
2Dh TOFF ü 290Eh R/W
2Eh CGAIN ü 4000h R/W
2Fh COFF ü 0000h R/W
30h–31h RESERVED — —
32h QResidual 20 ь ь 1306h R/W
33h–35h RESERVED — —
36h Iavg_empty ü 0780h R/W
37h FCTC ü 05E0h R/W
38h RCOMP0 ь ь 004Bh R/W
39h TempCo ь ь 262Bh R/W
3Ah V_empty ü 9C5Ch R/W
3Bh RESERVED — —
3Ch RESERVED — —
3Dh FSTAT ü 0001h R
3Eh TIMER ü 0000h R
3Fh SHDNTIMER ü E000h R/W
40h–41h RESERVED — —
42h QResidual 30 ь ь 0C00h R/W
43h–44h RESERVED — —
45h dQacc ü 007Dh R/W
46h dPacc ü 0C80h R/W
47h–4Ch RESERVED — —
4Dh QH ü 0000h R/W
4Eh–7Fh RESERVED — —
80h–AFh
Characterization
Table
ü N/A R/W
B0h–FAh RESERVED — —
FBh VFOCV ü 0000h R
FCh–FEh RESERVED — —
FFh SOC
VF
ü 0000h R
