MAX17047
ModelGauge m3 Fuel Gauge
Figure 61. TOFF Register Format (Input)
Table 5. Device Memory Map
ADDRESS
(HEX)
REGISTER NAME
A/D
MEASURE
ALERT/
STATUS
MG m3
APP
DATA
MG m3
CELL
DATA
MG m3
CONFIG
MG m3
SAVE AND
RESTORE
MG m3
OUTPUT
POR
VALUE
READ/
WRITE
00h Status ü 0002h R/W
01h V
ALRT
Threshold ü FF00h R/W
02h T
ALRT
Threshold ü 7F80h R/W
03h S
ALRT
Threshold ü FF00h R/W
04h AtRate ü 0000h R/W
05h RemCap
REP
ü 03E8h R
06h SOC
REP
ü 3200h R
07h Age ü 6400h R
08h Temperature ü 1600h R/W
09h V
CELL
ü B400h R
0Ah Current ü 0000h R
0Bh AverageCurrent ü 0000h R
0Ch RESERVED — —
0Dh SOC
MIX
ü 3200h R
0Eh SOC
AV
ü 3200h R
0Fh RemCap
MIX
ü 03E8h R
10h FullCAP ь ь 07D0h R/W
11h TTE ü 0000h R
12h QResidual 00 ь ь 1E2Fh R/W
13h FullSOCThr ü 4600h R/W
14h–15h RESERVED — —
16h AverageTemperature ü 1600h R
17h Cycles ь ь 0000h R/W
18h DesignCap ü 07D0h R/W
19h AverageV
CELL
ü B400h R
1Ah MaxMinTemperature ü 807Fh R/W
1Bh MaxMinV
CELL
ü 00FFh R/W
1Ch MaxMinCurrent ü 807Fh R/W
1Dh CONFIG ü 2350h R/W
1Eh ICHGTerm ü 03C0h R/W
1Fh RemCap
AV
ü 03E8h R
20h RESERVED — —
21h Version ü 00ACh R
Figure 61
MSB—ADDRESS 2Dh LSB—ADDRESS 2Dh
S 2 6 2 6 2 5 2 4 2 3 2 2 2 1 2 0 2 -1 2 -2 2 -3 2 -4 2 -5 2 -6 2 -7
MSb LSb MSb LSb
2 -7 UNITS: +0.0078NC
