W9864G2GH
- 36 -
Operating Timing Example, continued
14.13 Bust Read and Single Write (Burst Length = 4, CAS Latency = 3)
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23
CLK
(CLK = 100 MHz)
Q Q Q Q D D D Q Q Q Q
Read Read Single Write Active Bank #0
Idle
Bank #1
Bank #2
Bank #3
CS
RAS
CAS
WE
BS1
A10
A0-A9
DQM
CKE
DQ
t RCD
RBa
RBa CBv CBw CBx CBy CBz
av0 av1 av2 av3 aw0 ax0 ay0 az0 az1 az2 az3
t AC t AC
BS0
