9. DC CHARACTERISTICS
9.1 Absolute Maximum Rating
PARAMETER SYM. RATING UNIT NOTES
Input, Column Output Voltage V IN , V OUT -0.3~ VCC +0.3V V 1
Power Supply Voltage VCC , VCC Q -0.3~4.6V V 1
Operating Temperature T OPR 0 − 70 °C 1
Storage Temperature T STG -55 − 150 °C 1
Soldering Temperature (10s) T SOLDER 260 °C 1
Power Dissipation P D 1 W 1
Short Circuit Output Current I OUT 50 mA 1
Note : Exposure to conditions beyond those listed under Absolute Maximum Ratings may adversely affect the life and reliability
of the device.
10. RECOMMENDED DC OPERATING CONDITIONS
(T A = 0 to 70°C)
PARAMETER SYM. MIN. TYP. MAX. UNIT NOTES
Power Supply Voltage VCC 3.0 3.3 3.6 V
Power Supply Voltage (for I/O Buffer) VCC Q 3.0 3.3 3.6 V
Power Supply Voltage(-7) VCC 2.7 3.3 3.6 V
Power Supply Voltage
(for I/O Buffer)(-7)
VCC Q 2.7 3.3 3.6 V
Input High Voltage V IH 2 - VCC +0.3 V 1
Input Low Voltage V IL -0.3 - +0.8 V 2
Output logic high voltage VOH 2.4V - - V IOH=2mA
Output logic low voltage VOL - - 0.4 V IOL= 2mA
Input leakage current ILI -10 - 10 uA 3
Note : 1. VIH (max.) = VCC/VCCQ+1.2V for pulse width < 5 nS
2. VIL (min.) = VSS/VSSQ-1.2V for pulse width < 5 nS
3. Any input 0V < VIN < VCCQ.
Input leakage currents include Hi-Z output leakage for all bi-directional buffers with Tri-State outputs.
