RF12B
Tel: +86-755-86096587 Fax: +86-755-86096602 E-mail: [email protected] http://www.hoperf.com
FEATURES
z
Fully integrated (low BOM, easy design-in)
z
No alignment required in production
z
Fast-settling, programmable, high-resolution PLL synthesizer
z
Fast frequency-hopping capability
z
High bit rate (up to 115.2 kbps in digital mode and 256 kbps
z
in analog mode)
z
Direct differential antenna input/output
z
Integrated
power
amplifier
z
Programmable TX frequency deviation (15 to 240 kHz)
z
Programmable RX baseband bandwidth (67 to 400 kHz)
z
Analog and digital RSSI outputs
z
Automatic frequency control (AFC)
z
Data quality detection (DQD)
z
Internal data filtering and clock recovery
z
RX synchron pattern recognition
z
SPI compatible serial control interface
z
Clock and reset signals for microcontroller
z
16 bit RX Data FIFO
z
Two 8 bit TX data registers
z
Low power duty cycle mode
z
Standard 10 MHz crystal reference
z
Wake-up
timer
z
2.2 to 3.8 V supply voltage
z
Low power consumption
z
Low standby current (0.3 µA)
z
Supports very short packets (down to 3 bytes)
z
Excellent temperature stability of the RF parameters
TYPICAL APPLICATIONS
z
Remote
control
z
Home security and alarm
z
Wireless keyboard/mouse and other PC peripherals
z
Toy
controls
z
Remote keyless entry
z
Tire
pressure
monitoring
z
Telemetry
z
Personal/patient data logging
z
Remote
automatic meter reading
