RC1180-MBUS
 2008 Radiocrafts AS RC1180-MBUS Data Sheet (rev. 1.0) Page 16 of 28
Test mode 2 ‘2’ – 0x32 (none) TX modulated signal
PN9 sequence
Test mode 1 must be used
before 2 can be used.
Return to Test mode 1
before exiting configuration
mode
Note: ASCII characters are written as ‘X’, hexadecimal numbers are written like 0x00, and
decimal numbers are written like 10 throughout the text. A table of ASCII characters and their
respective hex and decimal values are found in the Appendix.
Any invalid command will be ignored and the ‘>’ prompt will be re-sent.
In order to use test mode 1 and 2, test mode 1 must always be set first. Modulation can then
be turned on using test command 2. The modulation must be turned off by using test mode 1
again before exiting the configuration mode (‘X’) in order to ensure proper operation in normal
mode.
Example:
To select RF channel 3, send the follow sequence after asserting the CONFIG line and the ‘>’
prompt is received:
Command Hex Response Comment/Note
Enter 0x00 ‘>’ Or assert CONFIG pin
De-assert CONFIG after ‘>’ prompt
‘C’ 0x43 ‘>’
3 0x03 ‘>’ Wait for ‘>’ prompt
[A new command could be issued here]
‘X’ 0x58 (none) Module returns to IDLE state
Note that the CONFIG line must be de-asserted after the first ‘>’ prompt was received, but
before the ‘X’ command.
