0V to 16V, Dual Hot-Swap Controller with 10-Bit

Current and Voltage Monitor and 4 LED Drivers

MAX5970

______________________________________________________________________________________ 29

Table 35. ADC Maximum Voltage Conversion Register Format (Low-Order Bits)

Table 36. Peak-Detection Reset-Control Register Format

Table 37. Peak-Detection Hold-Control Register Format

Using the Voltage and Current

Peak-Detection Registers

The voltage and current minimum- and maximum-value
records in register locations 0x08 through 0x17 can be
reset by writing a 1 to the appropriate location in register
peak_log_rst (see Table 36). The minimum-value regis-
ters are reset to 0x3FF, and the maximum-value registers
are reset to 0x00.
As long as a bit in peak_log_rst is 1, the corresponding
peak-detection registers are disabled and are cleared
to their power-up reset values. The voltage and current

minimum- and maximum-detection register contents
for each signal can be held by setting bits in register
peak_log_hold (see Table 37). Writing a 1 to a location
in peak_log_hold locks the register contents for the cor-
responding signal and stops the min/max detection and
logging; writing a 0 enables the detection and logging.
Note that the peak-detection registers cannot be cleared
while they are held by register peak_log_hold.
The combination of these two control registers allows the
user to monitor voltage and current peak-to-peak values
during a particular time period.

Description:

Maximum voltage conversion result, low-order bits [1:0]

Register Title:

max_ch0_mon_lsb

max_ch1_mon_lsb

Register Addresses:

0x0F

0x13

R

R

R

R

R

R

R/W

R/W

RESET

VALUE

vmax_1

vmax_0

0x00

bit 7

bit 6

bit 5

bit 4

bit 3

bit 2

bit 1

bit 0

Description:

Reset control bits for peak-detection registers

Register Title:

peak_log_rst

Register Address:

0x41

R

R

R

R

R/W

R/W

R/W

R/W

RESET

VALUE

Ch1_v_rst

Ch1_i_rst

Ch0_v_rst

Ch0_i_rst

0x00

bit 7

bit 6

bit 5

bit 4

bit 3

bit 2

bit 1

bit 0

Description:

Hold control bits for peak-detection registers; per signal

Register Title:

peak_log_hold

Register Address:

0x42

R

R

R

R

R/W

R/W

R/W

R/W

RESET

VALUE

Ch1_v_hld

Ch1_i_hld

Ch0_v_hld

Ch0_i_hld

0x00

bit 7

bit 6

bit 5

bit 4

bit 3

bit 2

bit 1

bit 0
