Table 14. ADC Minimum Current Conversion Register Format (Low-Order Bits)
Table 15. ADC Maximum Current Conversion Register Format (High-Order Bits)
Table 16. ADC Maximum Current Conversion Register Format (Low-Order Bits)
Description: Minimum current conversion result low-order bits [1:0]
Register Title: min_ch0_cs_ lsb min_ch1_cs_ lsb
Register Addresses: 0x09 0x11
R R R R R R R R
RESET
VALUE
imin_1 imin_0 0x03
bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
Description: Maximum current conversion result high-order bits [9:2]
Register Title: max_ch0_cs_msb max_ch1_cs_msb
Register Addresses: 0x0A 0x12
R R R R R R R R
RESET
VALUE
imax_9 imax_8 imax_7 imax_6 imax_5 imax_4 imax_3 imax_2 0x00
bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
Description: Maximum current conversion result low-order bits [1:0]
Register Title: max_ch0_cs_ lsb max_ch1_cs_ lsb
Register Addresses: 0x0B 0x13
R R R R R R R R
RESET
VALUE
imax_1 imax_0 0x00
bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
