0V to 16V, Dual Hot-Swap Controller with 10-Bit

Current and Voltage Monitor and 4 LED Drivers

MAX5970

12 _____________________________________________________________________________________

Detailed Description

The MAX5970 includes a set of registers that are
accessed through the I

2

C interface. Some of the registers

are read only and some of the registers are read and write
that are updated to configure the MAX5970 for a specific
operation. See Tables 1a and 1b for the registers map.

Table 1a. Register Address Map (Channel Specific)

REGISTER

DESCRIPTION

CHANNEL 1

CHANNEL 2

RESET
VALUE

READ/

WRITE

adc_chx_cs_msb

High 8 bits ([9:2]) of latest current-signal
ADC result

0x00

0x04

R

adc_chx_cs_lsb

Low 2 bits ([1:0]) of latest current-signal ADC
result

0x01

0x05

R

adc_chx_mon_msb

High 8 bits ([9:2]) of latest voltage-signal
ADC result

0x02

0x06

R

adc_chx_mon_ lsb

Low 2 bits ([1:0]) of latest voltage-signal
ADC result

0x03

0x07

R

min_chx_cs_msb

High 8 bits ([9:2]) of current-signal minimum
value

0x08

0x10

0xFF

R

min_chx_cs_ lsb

Low 2 bits ([1:0]) of current-signal minimum
value

0x09

0x11

0x03

R

max_chx_cs_msb

High 8 bits ([9:2]) of current-signal maximum
value

0x0A

0x12

0x00

R

max_chx_cs_ lsb

Low 2 bits ([1:0]) of current-signal maximum
value

0x0B

0x13

0x00

R

min_chx_mon_msb

High 8 bits ([9:2]) of voltage-signal minimum
value

0x0C

0x14

0xFF

R

min_chx_mon_ lsb

Low 2 bits ([1:0]) of voltage-signal minimum
value

0x0D

0x15

0x03

R

max_chx_mon_msb

High 8 bits ([9:2]) of voltage-signal maximum
value

0x0E

0x16

0x00

R

max_chx_mon_ lsb

Low 2 bits ([1:0]) of voltage-signal maximum
value

0x0F

0x17

0x00

R

uv1thr _chx_msb

High 8 bits ([9:2]) of undervoltage warning
(UV1) threshold

0x1A

0x24

0x00

R/W

uv1thr_chx_ lsb

Low 2 bits ([1:0]) of undervoltage warning
(UV1) threshold

0x1B

0x25

0x00

R/W

uv2thr_chx_msb

High 8 bits ([9:2]) of undervoltage critical
(UV2) threshold

0x1C

0x26

0x00

R/W

uv2thr_chx_ lsb

Low 2 bits ([1:0]) of undervoltage critical
(UV2) threshold

0x1D

0x27

0x00

R/W

ov1thr_chx_msb

High 8 bits ([9:2]) of overvoltage warning
(OV1) threshold

0x1E

0x28

0xFF

R/W

ov1thr_chx_ lsb

Low 2 bits ([1:0]) of overvoltage warning
(OV1) threshold

0x1F

0x29

0x03

R/W
