Grouping Hot-Swap Channels

The MAX5970 can operate as either two independent
hot-swap controllers or as a pair. See Table 2 for the
configuration option based on the MODE logic level.

Hot-Swap Channels On-Off Control

Depending on the configuration of the Chx_EN1 and
Chx_EN2 bits, when V

IN

is above the V

UVLO

threshold

and the ON_ input reaches its internal threshold, the
MAX5970 turns on the external n-channel MOSFET for
the corresponding channel, allowing power to flow to the
load. The channel is enabled depending on the output of
a majority function. Chx_EN1, Chx_EN2, and ON_ are the
inputs to the majority function and the channel is enabled
when two or more of these inputs are 1.

(Channel enabled) = (Chx_EN1 x Chx_EN2) +

(Chx_EN1 x ON_) + (Chx_EN2 x ON_)

The inputs ON_ and Chx_EN2 can be set externally; the
initial state of the Chx_EN2 bits in register chxen is set
by the state of the HWEN input when V

IN

rises above

V

UVLO

. The ON_ inputs connect to internal precision

analog comparators with a 0.6V threshold. Whenever
V

ON_

is above 0.6V, the corresponding ON_ bit in regis-

ter status1[0:1] is set to 1. The inputs Chx_EN1 and Chx_
EN2 can be set using the I

2

C interface; the Chx_EN1

bits have a default value of 0. This makes it possible to
enable or disable each of the MAX5970 channels inde-
pendently with or without using the I

2

C interface (see

Tables 3, 4a, and 4b).

Table 1b. Register Address Map (General) (continued)

Table 2. Grouping Hot-Swap Channels

Table 3. chxen Register Format

REGISTER

DESCRIPTION

ADDRESS

(HEX CODE)

RESET
VALUE

READ/

WRITE

LED_Flash

LED flash/GPIO enable register

0x43

0x00

R/W

LED_ph_pu

LED phase/weak pullup enable register

0x44

0x00

R/W

LED_state

LED pins voltage state register (LED pins set open)

0x45

0x00

R

MODE INPUT

FUNCTION

DESCRIPTION

Low

Independent

Each channel operates as an independent hot-swap controller. A fault
shutdown in one channel does not affect operation of other channel.

High/unconnected

Paired

Channel 0 and channel 1 operate together as one pair. A fault shutdown in
one channel shuts down both channels in the pair. Both channels share the
ADC monitoring capability.

Description:

Channel enable bits, from HWEN input and Chx_EN1 bits

Register Title:

chxen

Register Address:

0x3B

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

RESET
VALUE

Ch2_EN2

Ch2_EN1

Ch1_EN2

Ch1_EN1

bit 7

bit 6

bit 5

bit 4

bit 3

bit 2

bit 1

bit 0
