MAX19985A
Dual, SiGe, High-Linearity, 700MHz to 1000MHz
Downconversion Mixer with LO Buffer/Switch
_______________________________________________________________________________________ 3
RECOMMENDED AC OPERATING CONDITIONS
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
RF Frequency f RF (Note 5) 700 1000 MHz
LO Frequency f LO (Note 5) 900 1300 MHz
U si ng M i ni - C i r cui ts TC 4- 1W- 17 4:1 tr ansfor m er
as defined in the Typical Application Circuit,
IF matching components affect the IF
frequency range (Note 5)
100 500
IF Frequency f IF
Using alternative Mini-Circuits TC4-1W-7A
4:1 transformer, IF matching components
affect the IF frequency range (Note 5)
50 250
MHz
LO Drive Level P LO (Note 5) -3 +3 dBm
+5.0V SUPPLY AC ELECTRICAL CHARACTERISTICS
( Typical Application Circuit, V CC = +4.75V to +5.25V, RF and LO ports are driven from 50
Ω sources, P
LO = -3dBm to +3dBm,
P RF = -5dBm, f RF = 700MHz to 1000MHz, f LO = 900MHz to 1200MHz, f IF = 200MHz, f RF < f LO , T C = -40°C to +85°C. Typical values
are at V CC = +5.0V, P RF = -5dBm, P LO = 0dBm, f RF =900MHz, f LO = 1100MHz, f IF = 200MHz, T C =+25°C, all parameters are guaran-
teed by design and characterization, unless otherwise noted.) (Note 6)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
f IF = 200MHz, f RF = 824MHz to 915MHz,
T C = -40°C to +85°C
7.0 8.7 10.2
Conversion Power Gain G C
f IF = 200MHz, f RF = 824MHz to 915MHz,
T C = +25°C (Note 9)
7.7 8.7 9.7
dB
Conversion Power Gain Variation
vs. Frequency
∆G
C
Flatness over any one of three frequency
bands:
f
RF = 824MHz to 849MHz,
f RF = 869MHz to 894MHz,
f
RF
= 880MHz to 915MHz (Note 9)
0.15 0.3 dB
G ai n V ar i ati on Over Tem p er atur e TC G T C = -40°C to +85°C -0.012 dB/°C
T C = -40°C to +85°C 9.2 11.5
Noise Figure NF f
RF
= 850MHz, f
IF
= 200MHz,
P LO = 0d Bm , T C = + 25°C , V C C = + 5.0V
9.0 10.3
dB
Noise Figure Temperature
Coefficient
TC
NF
T
C
= -40°C to +85°C 0.018 dB/°C
Noise Figure Under Blocking
Condition
N
FB
+8dBm blocker tone applied to RF port,
f
RF = 900MHz, f LO = 1090MHz,
P LO = -3dBm, f BLOCKER = 800MHz,
V CC = +5.0V (Note 7)
18.8 22 dB
T C = -40°C to +85°C 10.0 12.6
Input 1dB Compression Point IP 1dB
T C = +25°C (Note 9) 11.0 12.6
dBm
f RF = 824MHz to 915MHz,
f RF1 - f RF2 = 1MHz, f IF = 200MHz,
P RF = -5dBm/tone, T C = -40°C to +85°C
22.5 25.5
Third-Order Input Intercept Point IIP3
f RF = 824MHz to 915MHz,
f RF1 - f RF2 = 1MHz, f IF = 200MHz,
P RF = -5dBm/tone, T C = +25°C (Note 9)
23.5 25.5
dBm
