MAX19995
Dual, SiGe, High-Linearity, 1700MHz to 2200MHz
Downconversion Mixer with LO Buffer/Switch
4 _______________________________________________________________________________________
+5.0V SUPPLY AC ELECTRICAL CHARACTERISTICS (continued)
( Typical Application Circuit optimized for the DCS/PCS band, R1 = R4 = 806
Ω, R2 = R5 = 2.32kΩ, V
CC = +4.75V to +5.25V, RF and
LO ports are driven from 50
Ω sources, P
LO = -3dBm to +3dBm, PRF = -5dBm, f RF = 1700MHz to 2000MHz, f LO = 1510MHz to
1810MHz, f IF = 190MHz, f RF > f LO , T C = -40°C to +85°C. Typical values are at V CC = +5.0V, P RF = -5dBm, P LO = 0dBm,
fRF = 1800MHz, f LO = 1610MHz, f IF = 190MHz, T C = +25°C, unless otherwise noted.) (Note 6)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
f RF1 - f RF2 = 1MHz, P RF = -5dBm per tone,
f RF = 2000MHz for min value
20.5 23.7
f IF = 190MHz, f LO = 1810MHz, f RF =
2000MHz for min value, f RF1 - f RF2 = 1MHz,
P RF = -5dBm per tone, T C = +25°C to
+85°C
21.5 23.7
Input Intercept Point IIP3
Typical Application Circuit optimized for
UMTS band (R1 = R4 = 681
Ω, R2 = R5 =
1.5k Ω), f
LO = 1760MHz, f IF = 190MHz,
f RF = 1950MHz, f RF1 - f RF2 = 1MHz,
P RF = -5dBm per tone
24.8
dBm
Input Intercept Variation Over
Temperature
TC IIP3
f RF1 - f RF2 = 1MHz, P RF = -5dBm per tone,
T C = -40°C to +85°C
0.0035 dBm/°C
Single sideband, no blockers present
(Note 8)
9 11
f LO = 1610MHz, f IF = 190MHz,
f RF = 1800MHz, T C = +25°C, P LO = 0dBm,
single sideband, no blockers present
(Note 8)
9 9.6
Noise Figure NF SSB
Typical Application Circuit optimized for
UMTS band (R1 = R4 = 681
Ω , R2 = R5 =
1.5k Ω), f
IF = 190MHz, f LO = 1760MHz,
f RF = 1950MHz, single sideband, no
blockers present
9.3
dB
Noise Figure Temperature
Coefficient
TC NF
Single sideband, no blockers present,
T
C = -40°C to +85°C
0.016 dB/°C
Noise Figure with Blocker NF B
f BLOCKER = 1900MHz, P BLOCKER =
+8dBm, f RF = 1800MHz, f LO = 1610MHz,
P LO = 0dBm, V CC = +5.0V, T C = +25°C
(Notes 8, 9)
19 20.5 dB
